Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P3.91 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD 2400-2700 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 3.91 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/8 Scanning | Module Size: | 250x250MM |
| Cabinet Size: | 500x1000MM | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 3-5 Years |
Square Plaza Advertising Screen on Rental P3.91 Industrial LED Displays
Application:
Ministry of Transport, police office, army office, energy department,meteorological department, water conservancy office
Government and enterprise, army office, communication center,airport, highway commanding center, police station ,energy and financial department
Specifications :
| Outdoor DIP P10 | |||||
| Resolution/mm | 3.91 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 65410/m² | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 250x250MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/8 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Characteristic:
1. High-strength wear-resistant and non-slip material is used, which can be stepped on directly, and can bear a load of up to 500 kg per square meter.
2. Seamless splicing and arbitrary combination of shells can be achieved, making the picture more exquisite and complete.
3. Virtual scene interaction can be achieved to experience magical interactive effects.
4. High contrast and high refresh rate design ensure that the screen has no delay and ghosting when rendering patterns.
5. Deep grayscale processing, RGB color and brightness are adjusted synchronously, the color is rich and delicate, clear and natural
6. Ultra-large viewing angle, better meet the needs of the stage
7. Professional heat dissipation channel design ensures that the heat of the screen is quickly and efficiently exported, so that the product performance is not affected by heat, and it is easy to disassemble and replace
8. Supports separate shells, which is more convenient for maintenance
9. The connector uses professional aviation plugs, and the quality and safety are guaranteed.
Uses: It can be widely used in bars, clubs, theaters, theaters, multi-function halls, cafes, hotels, stage performances, concert halls, commercial buildings, airports, shopping malls and other places.
|
1.The thin and light cabinet
|
|
2.High definition and exquisite image
|
|
3.Seamless Connection
|
|
4.Low consumption energy saving
|
Trade Terms:
FOB, CIF, EXW;
Payment Terms: T/T, Western Union, PayPal, L/C;
Payment Condition: 30% deposit in advance, 70% balance before delivery;
Delivery Time:5-7 working days after deposit,3-4 working days for inventory;
Packing: Neutral Carton,Flight case, Wooden case for large size;
Shipping: By sea, by air and by express delivery.
Contact Person: Lillian seori
Tel: +8619386814677
