RGB LED Display
Created with Pixso.

Full Color HD 3D P2.5 P3 P4 P5 P6 P8 P10 Waterproof Outdoor Large Video Wall Digital Advertising LED Display Billboard Screen

Full Color HD 3D P2.5 P3 P4 P5 P6 P8 P10 Waterproof Outdoor Large Video Wall Digital Advertising LED Display Billboard Screen

Brand Name: SCXK
Model Number: SCXK-P4
MOQ: 1sqm can be available
Price: negotiation
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability: 1000sqm/month. we can make the led display on time
Detail Information
Place of Origin:
China
Certification:
CE,ROHS ,FCC,UL ISO2001
Cabinet Size:
768mmx768mm
Display Color:
16.7million
Drive Mode:
1/16 Scan
Module Size:
256mm X128mm
Color:
Full Color
Warranty:
3 Years
Power Supply:
Meanwell Power Supply
Packaging Details:
the led display can be packaged with wooden box,paper box,flight case
Highlight:

Waterproof Outdoor LED Display Billboard

,

HD LED Display Billboard

,

P6 LED Display Billboard

Product Description

HD Full Color Rgb Led Display Board High Refresh Rate 768mmx768mm Cabinet



We insist better quality and after-sales service to our customers.

And guarantee all kinds of service to our cusotmers.



1.The cabinets, featuring great moisture and corrosion proofing,

enable themselves to work in all weather conditions.
2. Superb refresh rate provides you coherent video effects to

meet your needs for high display quality.
3. Superb cost effective offers you both top notch quality

and reasonable price, maximizing the value of your investment

Full Color HD 3D P2.5 P3 P4 P5 P6 P8 P10 Waterproof Outdoor Large Video Wall Digital Advertising LED Display Billboard Screen 0



Parameter as follows.



                                               The full color Indoor P4 led display parameter as follows.
LED Lamps Type SMD2121(High Brightness LEDs)
LED Standard Real Pixel(1R1G1B)
Red Wavelength 625-630nm
Green Wavelength 515-530nm
Blue Wavelength 465-475nm
LED Module Pixel Pitch 4mm
Module Size 256mm x128mm
Module Resolution 64*32dots
LED Cabinet Cabinet Size 768mmX768mm
Cabinet Resolution 192pixels *192pixels
Cabinets Material Sealed Iron Cabinet
LED Display Pixel Density 62500pixels/sq.m
Drive IC MBI5024
Power Supply Series connection
Brightness >2500cd/sqm
Display Color 16.7million
Viewing Angle 160°(Horizontal),110°(Vertical)
Best Viewing Distance 4m~200m
Max Power Consumption 600 w/sq.m
Average Power Consumption     300 w/sq.m
Weight 40kgs/sq.m
Refresh Rate 2000hz
Input Voltage AC220V/50H or AC110V/60H
Output Voltage DC5V,40A
Grey Scale Levels 16bit
Display Colors R(1024) x G(1024) x B(1024)
MTBF 10,000 hours
Life-span 100,000 hours
Protection Level IP43
Failure percentage of leds     less than 0.0003
Working Temperature -5℃~45℃
Drive Mode 1/16 scaning
Working Humidity 10%~99%



As the professional manufacturer, we will guarantee every pieces of the led display will be through the strictly test before

shipment. you can benefit from our long time business cooperation. The led display will be packaged well with wooden box.

Full Color HD 3D P2.5 P3 P4 P5 P6 P8 P10 Waterproof Outdoor Large Video Wall Digital Advertising LED Display Billboard Screen 1

Full Color HD 3D P2.5 P3 P4 P5 P6 P8 P10 Waterproof Outdoor Large Video Wall Digital Advertising LED Display Billboard Screen 2

Q1. What's the warranty of your LED Display Screen ?

A1. We have a 3-years warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2. What about your pre-sale service and post-sale service?

A2. For pre-sale service. We have a professional sales team and a 8 years technical team who are willing to answer your question 24/7.

We can offer a whole complete solution for your project!

For post-sale service. We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.

Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

Q3. Whats your payment term? How long it takes to delivery?

A3. We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.Our average Production time is 10 days, after receiving the deposit.

Q4. What's the control system?

A4. For synchronization control. We use Nova, Linsn Or Colorlight control system.

For asynchronous control We use Onbon, or Xixun control system.
