| Brand Name: | SCXK |
| Model Number: | P1.667 |
| MOQ: | 8 sqm |
| Price: | negotiation |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 sqm per month |
| Attribute | Value |
|---|---|
| Pixels | 1.667mm |
| Tube Chip Color | Full color |
| Cabinet | Iron or Aluminum For Options |
| Pixel configuration | 1R1G1B |
| Warranty | 3 years |
| Brand | SCXK |
4:3 design: Cabinet's 4:3 resolution is specialized for command center. Perfect replacement for LCD display.
Die cast aluminum cabinet guarantees a flat and seamless screen with good uniformity. Dot-to-dot correction technology provides pure image with great gradation.
Ultra wide angle of view ensures clear, natural images from any perspective, delivering a great subversive viewing experience.
| Resolution/mm | 1.667 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 360000/m² |
| Module resolution | 120x90 |
| Module size/mm | 200x150MM |
| View distance | 14-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >7500cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/30 SCANNING |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT, Windows1999, WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof, dustproof, high temperature protection, anti-corrosion, anti-burning, anti-static, anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
