Place of Origin: | ShenZhen in China |
Brand Name: | SCXK |
Certification: | CE/ROHS/FCC/ISO/CB |
Model Number: | P10 |
Minimum Order Quantity: | No limit |
---|---|
Price: | negotiation |
Packaging Details: | flight case, wooden case, carton, it is up to you. |
Delivery Time: | 7-10 working days after receive your payment |
Payment Terms: | T/T, Western Union |
Supply Ability: | 5000sqm per month |
Pixel Pitch: | 10mm | Tube Chip Color: | Full Color |
---|---|---|---|
Led Type: | SMD 3535 | Display Function: | Video/Text/Image |
Cabinet Material: | Iron | Frame Frequency: | >=60HZ |
Average NO Failure: | >=1000hours | Transmiiting Distance: | Internet Cable <100m |
Refresh Rate: | >=1920HZ | Power Supply: | AC80-260V±10%/50Hz,60Hz |
Highlight: | SMD IP65 outdoor LED display,P10 full color LED billboard,building advertising LED screen |
SMD IP65 Outdoor Full Color LED Display Screen P8 P10 Building Advertising LED Billboard
Parameter | Specification |
---|---|
Resolution/mm | 10 |
Pixel configuration | 1R1G1B |
Pixel density/pixels/m² | 10000m2 |
Module resolution | 32*16 |
Module size/mm | 320*160 |
View distance | 10-300m |
Single point brightness adjust | Can be added |
Single point color adjust | Can be added |
White balance brightness | >5000cd/㎡ |
Color temperature | 6500K-9500K |
Horizontal view angle | 120(degrees) |
Vertical view angle | 60(degrees) |
Signal Process bit | 10 or 16bit |
Driving mode | Constant driving current |
Scanning mode | static dring |
Frame rate | 60Hz |
Refresh frequency | 3000Hz |
Control mode | Computer synchronous |
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
Out of control point | <1/10000 |
Working hours | >72hours |
Mean time Between Failure | >500hours |
life time | >100000hours |
Envirornment temperature range | operating temperature range -200c-500c |
Maximun power :/m2 | <800w |
Average power:/m2 | <300w |
Self-check technolog | LEDspot self-check,communication check,power check,temperature monitor(need customization) |
Remote monitoring | Remote supervision and control,record potential fault send out warning signs to the operators(need customization) |
Software environment | windows NT,Windows 1999,Windows XP |
Input power cable | AC110v to220v |
Signal input | DVI |
Warranty | 2years quality warranty ,10 years spare parts support |
To be the premier provider of creative, marketing and innovative solutions devoted to helping other companies succeed and grow.
Packing: wooden case, flight case for choose
Shipping: by air, sea, train, DHL, you are the boss
Contact Person: Susan_zhang
Tel: +8618344159301
