Name: Indoor Front And Rear Access Easy Maintenance Full Color P4 LED Video Wall Screen
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P4
Price: 10000.00 USD
Availability: InStock

Home Products Indoor Full Color LED Display

Indoor Front And Rear Access Easy Maintenance Full Color P4 LED Video Wall Screen

Product Details:

Place of Origin:	ShenZhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB
Model Number:	P4

Payment & Shipping Terms:

Minimum Order Quantity:	3 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T, Western Union
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixel Pitch:	4mm	Tube Chip Color:	Full Color
Led Type:	SMD 2121	Display Function:	Video/Text/Image
Average NO Failure:	>=1000hours	Refresh Rate:	>=1920HZ
Power Supply:	AC80-260V±10%/50Hz,60Hz	Driving Mode:	1/16scan
Highlight:	P4 LED video wall screen , indoor full color LED display , easy maintenance LED video wall

Indoor Front And Rear Access Easy Maintenance Full Color P4 LED Video Wall Screen

Product Description

Front And Rear Access Easy Maintenance Full Color P4 LED Video Wall Screen

Module Parameter

Pixel pitch	4mm
Pixel configuration	1R1G1B
LED type	3-in-1 SMD 2121
Module size	256x128mm
Module resolution	64*64dots

Cabinet Parameter

Cabinet size	768x768mm
Cabinet material	simple ironed steel cabinet
Cabinet weight	12.5kg
Ingress protection	Front/Rear IP65/IP54

Whole Screen Parameter

Pixel density	62500 dots/m²
Brightness	≥1500 cd/m²
Viewing angle	H≥140° V≥140°
Min.viewing distance	4m
Max.power consumption	750W/m²
Avg.power consumption	300W/m²
Working voltage	110~220VAC±15%
Interface	HUB75
Colors	16.7millon colors
Gray level	14-16bits
Frame frequency	>1000frames
Refresh rate	>1920Hz
MTBF	≥100,000 hours
Lifespan	≥100,000 hours
Operating temperature	-10℃ ~ +40℃
Storage temperature	-20℃ ~ +60℃

Control System Parameter

Video signal (with video processor)	AV, S-video, VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature	Adjustable by software
Brightness level	256 levels, automatic adjustment by software
Control way	Computer, video-synchronous, real-time, off-line, wireless, internet etc.

LED Display Features

The brightness is very high: the brightness of the outdoor LED display is ≥6000cd/sqm, which is the only large display terminal that can be used outdoor all day long; the brightness of the indoor LED display is ≥ 1200cd/sqm.
Long life: LED life is up to 100,000 hours (ten years) or more, this parameter generally refers to the design life.
The viewing angle is large: the indoor viewing angle can be greater than 160 degrees, and the outdoor viewing angle can be greater than 120 degrees. The size of the viewing angle depends on the shape of the LED light emitting diode.
The screen area can be as small as less than one square meter, and as large as several hundred, thousands of square meters.
Easy to interface with the computer, support software rich.

Cabinet Photo

Company Profile

Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display, led indoor full color display, led wireless car usd screen, poster screen, transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality, good price product market to price product market to provide perfect product and service for our customers.

Certificate

Packaging and Shipping

Packing: 1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery: Shipping by sea, air or DHL, multiple shipping ways for your choice.

Our Service

Warranty

We guaratee all our display, modules, spare parts for TWO years.
We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
After warranty, we also can offer you the parts for replacement at our bottom price.
After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once. when we get it and offer you a good solution to solve the problem.
We also could solve problems for you antil it recovers well by remote control!

Installation

We can assist the training and technical support for the customer in the factory, if the customer require so.
We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need.
