Fields SMD P10 Outdoor Full Color LED Display Waterproof IP65,100000hours Operating Life

Fields SMD P10 Outdoor Full Color LED Display Waterproof IP65,100000hours Operating Life

Fields SMD P10 Outdoor Full Color LED Display Waterproof IP65,100000hours Operating Life
Fields SMD P10 Outdoor Full Color LED Display Waterproof IP65,100000hours Operating Life
Fields SMD P10 Outdoor Full Color LED Display Waterproof IP65,100000hours Operating Life
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: p10
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Control Mode: Computer Synchronous Resolution/mm: 10000
Frame Rate: 60Hz Driving Mode: Constant Driving Current
Optimal Viewing Distance: 10m~200m Warranty: 3 Or 5 Years
High Light:

led display smd

,

outdoor smd led display

Fields SMD P10 Outdoor Full Color LED Display Waterproof IP65,100000hours Operating Lifef IP65



♦ Our mission:



To be the premier providr of creative,marketing and innovative solutions devoted to helping other companies succeed and grow.





♦ Product Description



1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.





♦ Applications



 --- Outdoor and indoor advertising, digital billboards, advertising companies
 --- Sports halls, fields, playgrounds,school church
 --- Airports, bus stations and railway passenger terminals.
 --- Facades of shopping malls, department stores, banks and car dealerships.
 --- Architecture and social projects, information systems in cities.
 --- Show-business, concerts, festivals, motor shows and other public events.





♦ Technical specification



outdoor  SMD P10
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000/m²
Module resolution 16x16
Module size/mm 160x160
View distance 4-250m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode (1/4)
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/㎡ <950W
Average power:/㎡ <350W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast  (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Fields SMD P10 Outdoor Full Color LED Display Waterproof IP65,100000hours Operating Life 0

♦ Production process



1) Incoming Inspection→2)SMD→3)Plug-in

→4) Wave Soldering→5)After Welding→6)Testing

→7) Semi Finished Aging→8)Module Assembly

→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing





♦ Packaging and shipping



Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.





♦ Why choose us



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.



Fields SMD P10 Outdoor Full Color LED Display Waterproof IP65,100000hours Operating Life 1

♦ Frequently Asked Questions



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display  quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.
