No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor

No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor

  • No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor
  • No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor
  • No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor
  • No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor
No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor
Product Details:
Place of Origin: Shenzhen
Brand Name: SCX
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SCX-T16
Payment & Shipping Terms:
Minimum Order Quantity: 3 Square Meter/Square Meters
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 3000sqm per month
Contact Now
Detailed Product Description
Color Scale: 65536degree/1.07 Billion Colors Led Type: 3528
Pixel Configuration: 1r1g1b Model Number: T16
Pixels:: 16mm Brightness Adjustment: 64 Level Automatic Or Manual
Highlight:

led stage display

,

stage background led screen

IP65 Full Color Video Stage Led Display Module P16mm Indoor





Features

1. a newly Linear structure display product with high data refresh rate & brightness

2. sharp and exquisite video

3. light-weight and easy- installation

4. high temperature resistance and protection level 65



♦ Technical specification


Items

P16 outdoor led screen module

Pitch size

16mm

Module size

256mm*128mm

Module pixel(dots)

16*8

Pixel configuration

1Red,1Green,1Blue

LED chip

Silan/Cree/Nichia

Color scale

65536degree/1.07 billion colors

Pixel density

3906pixels/square meter

View angle(H/V)

120/60degree

Brightness

≥6500cd/sqm

Brightness adjustment

64 level automatic or manual

View distance

10--200m

Power consumption

100-1200/sqm

Net weight

<65kg/square meter

Operating temperature

—25°C~+60°C

Operating humidity

10%—95%RH

Life time

≥100,000hours

Out of control dot

≤3/10,000

Whole Display Flatness

≤1mm Juncture

Exchange frame speed

>150frames per second

Refresh frame frequency

600Hz

Control distance

Cat. 5: 120m (without repeater), single mode fiber:20km,multi mode fiber: 500m

Power

110V/220V±15% 50Hz

Operating system

Windows98/Me/2000/Xp

Drive mode

constant current driving, static scan

Display mode

VGA640X480—VGA1600X1024

Protections for outdoor display

IP65 for front, IP64 for rear

Maintenance way

rear access

Accepting signal

PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI





No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor 0No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor 1No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor 2No Mosaic HD IP65 Full Color Video Stage LED Display Module P16mm Indoor 3

 application
1) Full color LED display: Equally or compactly make the red, green, blue color in one dot, equally distribute at the panel, and so make the whole display
2). usually apply for physical sports, advertisement, bank, stock exchange, station, port, marketplace, telecommunication, department, school, monitor, restaurant, entertainment, etc.





Products function introduction

1) High brightness, adjustable, can meet customer requirements according to the application environment;
2) Good uniformity, well solve the mosaic problem, with excellent light consistency;
3) For images and text, it has a clear, delicate and real display effect;
4) Large viewing angle, up to 110 degrees horizontally and 60 degrees vertically. Within this range, no matter from which angle you watch, there will be no image change or color shift;
5) Each LED lamp can be repaired, so the maintenance cost is low and easy to repair.
