Waterproof Outdoor Full Color High Brightness Nationstar SMD P6 P8 P10 Advertising Led Screen

Waterproof Outdoor Full Color High Brightness Nationstar SMD P6 P8 P10 Advertising Led Screen

  • Waterproof Outdoor Full Color High Brightness Nationstar SMD P6 P8 P10 Advertising Led Screen
  • Waterproof Outdoor Full Color High Brightness Nationstar SMD P6 P8 P10 Advertising Led Screen
  • Waterproof Outdoor Full Color High Brightness Nationstar SMD P6 P8 P10 Advertising Led Screen
Waterproof Outdoor Full Color High Brightness Nationstar SMD P6 P8 P10 Advertising Led Screen
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL/CB/IECEE
Model Number: P8
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 8mm Module Size: 320*160mm
Module Pixel: 40*20 Module Weight: 0.5kg/pc
Cabinet Size(WXH): 960mmx960mm Cabinet Resolution: 120dotsx120dots
Module Quantity: 18pcs Pixel Density: 15625 Dots/m2
Material: Steel Brightness: ≥6000cd/㎡
High Light:

full color led signs outdoor

,

full color outdoor led display



Waterproof Outdoor Full Color High Brightness Nationstar SMD P6 P8 P10 Advertising Led Screen



Outdoor Full Color Led Screen Advantage


1. CE&RoHS certificate

2. 60 months warranty and Life long free tech-support

3. Excellent contrast ratio, high resolution/high definition

4. Perect uniformity and no mosaic

5. Waterproof IP65

6. Easy to install

7. Available models: P4, P5, P6, P8, P10 ect.

Outdoor Full Color LED Screen Specifications

Pixel pitch 8㎜
Module size 320*160(mm)
Cabinet size 960*960(mm)
Pixel density 15625 pixels /㎡
1R1G1B
Module resolution 40*20
Module weight 0.2㎏
Cabinet resolution 120*120
Cabinet area 0.9216m²
Cabinet weight 32KG±0.05KG
Main technical parameters
Best viewing distance 8m~72m
Visual Angle level≧160°
vertical≥160°
Average power<700W/㎡
Max power <1400w/㎡
Control mode: synchronous control
Display card DVI graphics card
Drive mode 1/4 scan
Max power ≤40W
Refresh rate ≧1920Hz
Brightness ≧5500cd/㎡
frame frequency≧50/60
Brightness adjustment mode
Automatic adjustment of brightness sensor
16 level is adjustable
Software manual adjustment: 100 level adjustable 100
Computer operating system
WIN98,WINXP,WIN2000,etc
The video signal
RF,S-Video,RGB,RGBHV,YUV,YC,COMPOSITION etc
Control system
PCTV card (optional) +DVI video card + master control card + optical fiber transmission (optional)
Average trouble-free time≧5000hours
life 75000~100000 hours
Pixel out of control rate <0.0002pcs
PH8-4S
SMD
LED3535


Outdoor Full Color Led Screen Production process
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

Waterproof Outdoor Full Color High Brightness Nationstar SMD P6 P8 P10 Advertising Led Screen 0


Our Service
1.We provide the best service to our every clients. before the order,send all the information to our clients. to help him make the decision. include the size. color. pictures,pack way and shipping way.

2.During the order, we need update the orders and feedback to him. keep him update with his order. such as how is his order,when will be finished,and also take the aging test pictures for his reference. at the same time. provide the packing pictures .after the goods delivery out. provide the tracking number. so that the clients can track his goods at any time.

3.The after-sale service: provide the one year warranty.during this year.the clients can obtain maintain service in free. and also will provide some accessories to the customers.

4.Some products we can provide the certifications. such as CE certification.





FAQ

Q1:How to choose a proper led screen for your need?

A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in
one place forever)?
3.what is the size of the led screen do you need?

Q2:Which pixel pitch should I choose?

A:There are many different pixel pitch from 1.25--10mm, there is usually small pixel(1.667mm-4mm) used
for indoor led screen, bigger pixel (3mm-10mm) used for outdoor led screen(for example high way huge advertisement).

Q3:Which control system should I choose?

A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than
20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate
is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.

Q4:How to order from you compamy?

A:You can both place order to us by alibaba online or to our company directly offline, before place order welcome to contact us
for confirmation.

Q5:How to pay?

A:We accept payment online through alibaba, or offline to our company account by T/T bank, or paypal or westerunion.

Q6:How to ship?

A:It is optional and we respect customer's choice. You can choose to ship by air cargo, by DHL(Fedex,UPS etc) internation express
company, or by sea according to your goods weight and volume and the delivery time you need.

Q7:How to install it after i received it?

A:We will offer you the drawing to guide you for installation, we could also offer steel drawing, software set up drawing or photo
or send our engineer fly to you for help if needed.
