Waterproof P16 256mm x 128mm Outdoor Red Single Color P16 Led Module Display

Waterproof P16 256mm x 128mm Outdoor Red Single Color P16 Led Module Display

  • Waterproof  P16  256mm x 128mm Outdoor Red Single Color P16 Led Module Display
Waterproof  P16  256mm x 128mm Outdoor Red Single Color P16 Led Module Display
Product Details:
Place of Origin: China
Brand Name: SCX
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SCX-T16
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T or western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 16mm Screen Dimension:: 256*128mm
Resolution:: 32X16dots Module Size:: 320x160mm
Brightness:: More Than 2000cd/sqm Waterpoof Grade:: IP65
Power Consumption:: Maximum 300w/m2 Warranty Time:: 2 Years
High Light:

moving led screen

,

digital led sign

waterproof  P16  256*128mm outdoor red single color P16 led module display







Specifications

 1, the red,green,blue, white and yellow color can be choose.

  2, outdoor water-proof and semi-outdoor led display design

  3, The size can be design by customer

  4, The simple frame and water-proof cabinet

  5, 2 years warranty and more than 10 years life use

  6, View angle;H:100 v:50  DC:5V





Applications:

 The single color led display is very popular in LED display advertising field.

This type digital billboards are widely used  ,store ,stadium,shopping ,airport etc;





Technical parameter

No.

Specifications



1.

Part No.

P16 OUTDOOR LED DISPLAY Screen

2.

LED chip

Taiwan/Silan/Cree/Cree Cotco

3.

Physical Pixel Pitch

10mm

4.

Physical Pixel Density

3906dots/m2

5.

Pixel composition

1Red

6.

Moduel Size

256*128mm

7.

Moduel resolution

16*16dots

8.

Cabinet thickness

< 170 mm

9.

Bracket of cabinet

Easy to install onto the LED cabinet and unistall .

10.

Brightness

≥ 6500 nits

11.

Colors

16.7million

12.

Viewing angle

Horizontal ≥120°,   Vertical  : ≥  45°

13.

Viewing distance

10m -300m

14.

Soft Rubber Mask

To protect player and LED display itself .

15.

Scan frequency

≥600 Hz

There will be one receive card in each cabinet  ,so that the LED display won't sparked .Also it is very easy to move and connetct

16.

Video Frame Rate

≥150 fps

17.

Color temperature

6500°K to 9500°K adjustable

18.

Control method

Controlled by PC, synchronous display

19.

Life span( half brightness)

≥100,000 hours

20.

Weight

70Kg  /sqm

21.

IP rate

IP65 ( front side and rear side)

22.

Average power consumption

400W/sqm

23.

Peak power consumption

1300W/sqm

24.

Input voltage

AC220V/50Hz ±10%    or  AC110V/60Hz ±10%  or AC380V/60Hz ±10%

25.

Operating Environment

Temperature:-20+60      Humidity:10%95%RH

26.

Operating system

Windows 98/2000/ME/XP

27.

Type of video signal

S-video, composite video ,RGB ,VGA ,DVI





 Product advantages:
1) Price Advantage: we have the best competitive price at the market, also have the same even better quality.

 2) Quality advantage: From material to finished product, from design to produce, we control all steps

 3) Service advantage: Better service at same situation, better cooperation at same service



Trade Terms:
1).Payment: T/T ,ususally 40% prepayment before production, 60% balance to be paid before delivering,it also change according to total quantity
2).Production lead time  less 20 sqm: 8-10days, more than 50 sqm:30days
3).Sample can be deliveried within 3days
4).Shipping port: Shenzhen, Mainland China
5).Discounts are offered based on order quantities
6).MOQ:1 sqm/1pcs





 Our service:

1).Your inquiry related to our products or prices will be replied in 24hrs.
2).Well-trained and experienced staffs to answer all your enquires in fluent English .
3).OEM&ODM, any your customized screen we can help you to design and put into product.
4).Distributer ship are offered for your unique design and some our current models .
5).Protection of your sales area, ideas of design and all your private information
