High resolution full color DIP SMD P10 sport perimeter stadium led display

High resolution full color DIP SMD P10 sport perimeter stadium led display

    • High resolution full color DIP SMD P10 sport perimeter stadium led display
    • High resolution full color DIP SMD P10 sport perimeter stadium led display
    • High resolution full color DIP SMD P10 sport perimeter stadium led display
    • High resolution full color DIP SMD P10 sport perimeter stadium led display
  • High resolution full color DIP SMD P10 sport perimeter stadium led display

    Product Details:

    Place of Origin: China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P10

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Product Name: High Resolution Full Color DIP SMD P10 Sport Perimeter Stadium Led Display Pixels: 10mm
    Resolution: 10000 Dots Per Sqm Module Resolution: 32x16
    Life Span: 100000 Hours Warranty: 5 Years

    High resolution full color DIP SMD P10 sport perimeter stadium led display





    ♦Description:

    •With sensitive control system, it can adjust screen brightness automatically according to the lighting change of indoor and outdoor, saving energy to reduce your operating costs greatly.
    •High refresh rate and high gray make the picture more realistic, which meets the demand of high visual quality of commercial usage.
    •The advertising contents can be changed at any time, for different customers and various advertisements.
    •you can know the display operation anytime, anywhere.
    • it can turn on and turn off the screen by software timing or manually at any time, achieving unattended function.



    ♦ Quick Detail

    1. Super lighter and thinner;


    2. Easy to connection and uninstall;


    3. It can display,words,texts,graphics and videos.

    4. High resolution and high frequency dynamic image.



    ♦ Our advantages

    Professional Manufacturer of led display

    1. OEM service,No MOQ

    2. Easy installation,regular items in Stocks

    3. Offering free design drawing as requested.

    4. Remote controlling and adjusting are available.

    5. Wooden case or flight case,you are the boss.

    6. Your reply will be replied within 24 hours.

    7. Fast delivery: Usually 6-8 working days

    8. Excellent R&D team,factory Price and assure you quality goods.



    ♦ Product specification

    outdoor P10
    Resolution/mm 10
    Pixel configuration 1R1G1B
    Pixel density/pixels/m² 10000/m²
    Module resolution 32x16
    Module size/mm 320x160
    View distance 9-500m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >8000cd/㎡
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 60(degrees)
    Signal Process bit 10 or 16bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
    Driving mode Constant driving current
    Scanning mode (1/4)
    Frame rate 60Hz
    Refresh frequency >3000Hz
    Control mode Computer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted

    255 steps. No grey loss

    Out of control point <1/10000
    Working hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃
    Maximum power:/㎡ <750W
    Average power:/㎡ <250W
    Self-check technology

    LED spot self-check, communications check, power check,

    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,

    send out warning signs to the operators.(need customization)

    Software environment WindowsNT,Windows1999,WindowsXP
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%



    High resolution full color DIP SMD P10 sport perimeter stadium led display

    High resolution full color DIP SMD P10 sport perimeter stadium led display



    ♦ Production process:

    1) Incoming Inspection→2) SMD→3) Plug-in

    →4) Wave Soldering→5) After Welding→6) Testing

    →7) Semi Finished Aging→8) Module Assembly

    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing



    ♦ Packaging and shipping

    Wooden case or flight case package are available.

    Shipping by sea,air or DHL,multiple shipping ways for your choice.



    ♦ Why choose us:

    Continues Quality

    With more than 10 years experience in led display producing,equipments are updated regularly.What’s

    more,unique standardized and module production ensure our products continuous quality.

    Competitive Price

    With large scale production capacity and professional production technology,our company have built

    effective modular production.We always stick to promote the technical innovation and reduce cost to

    benefit customers.

    Fast Delivery

    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

    inventory will be used to maintain your uninterrupted supply of the products.

    Perfect Service

    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

    you.

    After-sales:We will track the products usage and then constantly perfect our products.
