High Brightness P4 SMD LED Screen with 1/16 Scan and 256×128mm Module for Indoor Full Color Display

Brand Name:	SCXK
Model Number:	SCXK-P4 indoor
MOQ:	1sqm
Price:	negotiation
Payment Terms:	T/T,Western Union
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

MADE IN CHINA

Certification:

CE/ROHS/FCC/ISO/UL

Module Size:

256*128mm

Pixel Pitch:

4mm

Resolution:

64mm*32mm

Viewing Angle:

Horizontal 110°, Vertical 50°

Operating Voltage:

AC220V±10% Or 110V±10%

Brightness:

≥3000cd/sq M

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

led display smd

smd led display

Product Description

High Brightness P4 SMD Full Color LED Screen Indoor Commercial Advertising

High definition and brightness P4 SMD Full Color LED Screen Indoor commercial advertising LED display, 1/16 Scan

Technical Specifications

Parameter	Specification
Pixel Tube	Pixel Pitch: 4mm; Primary Colors: Pure Red + Pure Green + Pure Blue; Color Composition: 3-in-1 or 1R1G1B; Density: 62,500 dots/sq m; SMD3528 and DIP346
Unit Box	Module Size: 256mm × 128mm; Module Resolution: 64×32; Cabinet Thickness: (Cold-roll steel sheet) 150mm + (Maintain) 600mm
Whole Screen	Optimum Viewing Angle: Horizontal 110°, Vertical 50°; Viewing Distance: 10-300m; Working Temperature: -20°C to +45°C (-30°C to +50°C optional); Relative Humidity: ≤95%RH; Drive IC: ET6024
Operating Voltage	AC220V±10% or 110V±10%; Average Consumption: 500 W/sq m; Max Consumption: ≤650 W/sq m
Main Parameters	Driving Mode: 1/16 scan Refreshing Rate: ≥400Hz/s Frame Frequency: ≥60Hz/s Gray Scale/Color: ≥16.7M colors (Synchronized) Manage Gray: ≥72bit Brightness: ≥3000cd/sq m Color Temperature: 3500K~9500K, adjustable Brightness Adjustment: Manual/Auto Video Signal: RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION etc. Signal Management: ≥12bit; Against Y revised curve: owns 3pcs above Y curve that can adjustable Average Trouble-free Time: ≥5000 hours Evenness: Between random adjacent pixel ≤0.5mm, module splicing space <1mm Switch Power Loading: 5V/40A Display Mode of Computer: 1024×768

LED Display Features

Wide Application & Short ROI

Suitable for commercial advertising, stadium perimeter, mobile trailers, shopping malls, banks, stock exchanges, transportation stations, airports, and telecommunications systems.

High Contrast Ratio

4000:1 contrast ratio ensures vivid and clear images on our LED display systems.

Premium LED Chips

Supplied by Nichia of Japan and other high-quality LED chips to ensure long lifetime and high brightness.

Superior Image Quality

Clear, vivid images even in direct sunlight to maximize audience engagement and ROI.

Quality Assurance Methods

Aging Process

100% fully tested
Condition: 72 hours with 256 gray level

Vibration Testing

Condition: 3-5 minutes up and down in 5mm range

Payment & Delivery

Payment Terms:

T/T: 30% deposit, 70% before shipment
100% Western Union in advance

Why Choose Us

Consistent Quality

Over 10 years of LED display production experience with regularly updated equipment and standardized module production.

Competitive Pricing

Large-scale production capacity and professional technology enable cost-effective solutions for customers.

Fast Delivery

Commitment to promised delivery dates with emergency inventory procedures for uninterrupted supply.

Perfect Service

Comprehensive pre-sales consultation and ongoing after-sales support with product usage tracking.

Frequently Asked Questions

What kind of payment terms do you accept?

We accept T/T and Western Union payments.

What about your LED Display quality?

Comprehensive quality checking throughout the manufacturing process and 100% inspection before shipment ensure consistent product quality.
