P8.9 large RGB Floor full color indoor led display , 5 Years Warranty

P8.9 large RGB Floor full color indoor led display , 5 Years Warranty

    • P8.9 large RGB Floor full color indoor led display , 5 Years Warranty
    • P8.9 large RGB Floor full color indoor led display , 5 Years Warranty
    • P8.9 large RGB Floor full color indoor led display , 5 Years Warranty
  • P8.9 large RGB Floor full color indoor led display , 5 Years Warranty

    Product Details:

    Place of Origin: China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: SMD P8.9

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: T/T, Western Union,
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Pixel Configuration: RGB 3 In 1 Name: Dance Floor Led Screen
    Pitch: 8.9mm Color Temperature: 6500K-9500K
    Package: Flight Cases Or Wooden Cases Warranty: 5 Years

    P8.9 large RGB Floor full color indoor led display , 5 Years Warranty



    ♦ Product details



    1.Multi function idea for standing HD screen and dance floor display.
    2.Waterproof front and back,idea for both indoor and outdoor rental.
    3.High brightness and small pitch,delivering vivid video image.
    4.Mask is easy to remove and install,anti-split and anti-scratch.
    5.Solid CNC die casting cabinets,surface overtakes 3 tons weight.
    6.No extra fixing bar needed on flooring,easy amd fast assemble.





    ♦ Product specification

    indoor  SMD P8.9
    Lamp size 3535
    Resolution/mm 8.9
    Pixel configuration RGB  3 in 1
    Pixel density/pixels/m² 15625/m²
    Module resolution 64x32
    Module size/mm 256x128
    View distance ≥3m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >3000cd/㎡
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 60(degrees)
    Signal Process bit 10 or 14 bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
    Driving mode Constant driving current
    Scanning mode 1/16
    Frame rate 60Hz
    Refresh frequency >4200Hz
    Control mode Computer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted

    255 steps. No grey loss

    Out of control point <1/10000
    Working hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
    Maximum power:/㎡ <1100W
    Average power:/㎡ <280W
    Self-check technology

    LED spot self-check, communications check, power check,

    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,

    send out warning signs to the operators.(need customization)

    Software environment WindowsNT,Windows1999,WindowsXP
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%



    Product Overviews

    Items Indoor Led display:
    P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10
    Outdoor Led display:
    P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
    Material steel,aluminum ,die casting aluminum
    Payment
    terms
    30% deposit before production, 70% balance before shipping
    T/T
    Western Union
    Packing: Standard Export Carton with fully Polyfoam or Pearl Wool
    Flight case;
    Anti-shaking wooden case
    Shipping: 5 to 7 working days upon receiving deposit payment
    After-Sales-Service: Lifetime with professional engineer support for free.
    Within 5 year, supply spare parts for free if has quality problem
    ( not by man-made damage)
    Using Range Shopping mall,bank,bus station, train station,
    center of downtown, airport, school, factory, bus, taxi,and so on.



    Service

    Pre-sale service:
    1.Reply enquiries in 24 hours.
    2.Market research and forecast for customer.
    3.Provide unique and professional solutions based on customer's requirement.
    4.Data sheet and samples offer.
    5.Other services, such as special packing design, factory visiting and so on.

    In-sale service:
    1.Tracking report in producing.
    2.Quality test report for every order.
    3.Photos and videos as per customer's requirement.
    4.Free spare parts.

    After-sale service:
    1.Lifetime free maintenance and upgrade.
    2.Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
    3.Customer satisfaction tracking report.
    4.Free technician training.
    5.Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
    6.Special service for big project, such as stadium, exhibitions, squares and so on.



    ♦ Production process:

    1) Incoming Inspection→2) SMD→3) Plug-in

    →4) Wave Soldering→5) After Welding→6) Testing

    →7) Semi Finished Aging→8) Module Assembly

    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing



    ♦ Packaging and shipping

    Wooden case or flight case package are available.

    Shipping by sea,air or DHL,multiple shipping ways for your choice.



    ♦ Why choose us:

    Continues Quality

    With more than 10 years experience in led display producing,equipments are updated regularly.What’s

    more,unique standardized and module production ensure our products continuous quality.



    Competitive Price

    With large scale production capacity and professional production technology,our company have built

    effective modular production.We always stick to promote the technical innovation and reduce cost to

    benefit customers.



    Fast Delivery

    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

    inventory will be used to maintain your uninterrupted supply of the products.



    Perfect Service

    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

    you.

    After-sales:We will track the products usage and then constantly perfect our products.
