Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved

Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved

Brand Name: SCXK
Model Number: P10
MOQ: 2 sqm
Price: negotiation
Payment Terms: Western Union, T/T
Supply Ability: 5000sqm per month
Detail Information
Place of Origin:
ShenZhen in China
Certification:
CE/ROHS/FCC/ISO/CB
Pixel Pitch:
10mm
Led Type:
SMD 3535
Display Function:
Video/Text/Image
Waterproof:
IP65
Transmiiting Distance:
Internet Cable <100m
Refresh Rate:
>=1920HZ
Module Size:
320*160mm
Pixel Density:
10000dots/㎡
Packaging Details:
flight case, wooden case, carton, it is up to you.
Highlight:

full color led signs outdoor

,

outdoor full color led screen

Product Description

Outdoor Waterproof IP 65Full Color P6 P8 P10 LED Display Video Wall CE Rohs Approved





Our Mission:



To be the premier providr of creative, marketing and innovative solutions devoted to

helping other companies succeed and grow.



Product Description



1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable

for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging

technology for nice image.



♦ Applications



--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.



♦ Technical Specification

Outdoor SMD P10
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000m2
Module resolution 32*16
Module size/mm 320*160
View distance 10-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >5000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Driving mode Constant driving current
Scanning mode static dring
Frame rate 60Hz
Refresh frequency 3000Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours  >72hours
Mean time  Between Failure >500hours
life time >100000hours
Envirornment temperature range operating temperature range  -200c-500c
Maximun power :/m2 <800w
Average power:/m2 <300w
Self-check technolog LED spot self-check, communication check, power check, temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault send out warning signs to the operators(need customization)
Software environment Windows 1999, Windows
Input power cable AC110v to 220v
Signal input DVI
Warranty 2 years quality warranty, 10 years spare parts support





Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved 0

Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved 1

Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved 2

Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved 3

Control System

Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved 4

Certificates:

Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved 5



♦ Our Mission:



To be the premier providr of creative, marketing and innovative solutions devoted to helping other companies succeed and grow.



Why Choose us?

Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved 6



Packing&Shipping



Packing: wooden case, flight case for choose

shipping: by air, sea, train, DHL, you are the boss

Outdoor Waterproof IP65 Full Color P10 LED Display Video Wall CE Rohs Approved 7



FAQ



1. How can I place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /Whatsapp, in case of any delays.

2. What kind of display do we provide?
We have indoor/outdoor/mobile LED /rental LED display /LED stage/ Advertising LED display for you to choose. The customized service also could be provided

3. What about the lead time for an order?
Always: 7-17 days after receiving your payment, as your order quantity, sometimes we have stock, can delivery within 7 days

4. What about the warranty?
We have 2~5 years of quality guaranteed, spare parts such as the led module, receiving card, control card, power supply are damaged not cause of artificial damaged, then it's free maintenance and ship back new ones for replacement.

5.How about the quality?

Our led products must be testing of at least 72hours before shipping, from purchase raw materials to ship, Each step has strict quality control systems to ensure led display with good quality

6. Can you offer technical support? Since it's my first time....
We provide free training for our customer, teach the client how to set up screens, make configuration of parameters, broadcast the videos through Nova star and colorlight or Linsn control systems, our engineer can directly teach you how to control, or help you to do if you are really don't know how to control (Our Engineer can text English, we can saving more time).
