Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | Shenzhen in China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/CB |
| Model Number: | P4 |
| Minimum Order Quantity: | 3 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | Western Union, MoneyGram, D/P, T/T |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | 4mm | Tube Chip Color: | Full Color |
|---|---|---|---|
| Led Type: | SMD2121 | Display Function: | Video/Text/Image |
| Cabinet Material: | Die- Catsing Aluminum / Iron | Working Voltage: | DC5V |
| Warranty Time: | 3~5 Years | Pixel Density: | 62500 Dots/sqm |
| Driving Mode: | 1/16 Scaning | ||
| Highlight: | led full color screen,indoor led display screen |
||
High Resolution 3 in 1 Indoor Full Color LED Display High definition 4mm Pixel pitch
Specifications :
| Indoor SMD P4 | |||||
| Resolution/mm | 4 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 62500/m² | ||||
| Module resolution | 80x40 | ||||
| Module size/mm | 320x160MM | ||||
| View distance | ≥4m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >1000cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/20 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Features:
High Brightness:Viewers can see the images clearly at a long distance in sharp sunlight because of using high brightness LED lamps.
Long lifetime: Adopting high quality LED lamps as core material and patent PCB design for the screen, it
essentially ensures long lifetime of the product.
Stable performance:We make a special treatment of anti-electromagnetic wave and adopt distribution scan and
modular design for the screen and it works more reliable and stable.
Exquisite images:Nonlinearity correction technology makes the images exquisite and clear, video images vivid
and fidelity.
Excellent flatness:Precision design of module frame parts controls the deviation of neighbouring modules within 0.1mm and it has an excellent flatness without mosaic.
High contrast: Consistent deep black and patent masks make the contrast higher and the color fresher.
Easy installation:Modular design makes the installation and maintenance easier.
Good material:Adopting same levels of imported LED chips from Taiwan, USA or Japan, high quality driving IC,low noise power supply, which can guarantee the screen work smooth in the environment of -40~60.
Multiple formats: Customers can choose any one of display formats for the screen, it can supports TXT, graphic,picture, animation and video programs.
Lacquer coating:Lacquer coasting can protect the PCB and relevant components from erosion of environment, it has the good resistanceperformance of low and high temperature, and excellent features of insulation, moisture proof, anti-creeping, dustproof, anti-corrosion.
High shockproof performance:The cabinets must be tested for shockproof performance before shipment to
avoid poor contact because of loose of screws and disconnection of cables after long line-haul.
High waterproof performance:The cabinet must be treated for waterproof performance during production, and its front and back can be fully waterproof and it can work smoothly in outdoor all-weather.
Trading Terms:
Customs
1. The price you paid for the item excludes any customs tax.Our company does not shoulder any duties in destination company.
2. We are trying to help you to minimize or avoid any GST or VAT,or other Import Taxes,but we cannot guarantee no tax charges as it depends on your country’s policy.
3.Please be informed that the Customs Office in all countries have their right to inspect all the mails for their countries and levy the customs charges for the items. And SCX co.,ltd isn't responsible for any importing Duty/Tax.
Shipping
1. SCX has signed shipment agreement with famous express company agents (Like DHL, FedEx, TNT and EMS). And can get great discount from them, we can offer cheapest shipment cost to you. And the Shipment is traceable online. We will tell you the tracking number as soon as we ship out.
2. Items are shipped after payment is confirmed.
3. We ship items via EMS,DHL,UPS,FEDEX or Airmail.
4. We're not responsible for any accidents ,delays or other issues that are the responsibility of shipping service.
5. Any importing charges or fees are the buyer's responsibility.
FAQ:
Contact Person: Susan_zhang
Tel: +8618344159301
