Outdoor P8 SMD Full Color LED Billboard IP65 Waterproof 8mm Pitch

Outdoor P8 SMD Full Color LED Billboard IP65 Waterproof 8mm Pitch

Brand Name:	SCXK
Model Number:	P8
MOQ:	5 sqm
Price:	317$-552$
Payment Terms:	T/T,Western Union
Supply Ability:	5000 sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen China

Certification:

CE/ROHS/FCC/ISO/CB

Pixel Pitch:

8mm

Tube Chip Color:

Full Color

Waterproof:

IP65

Cabinet Material:

Iron Or Aluminum For Options

Frame Frequency:

>=60HZ

Average NO Failure:

>=1000hours

Transmiiting Distance:

Internet Cable <100m

Refresh Rate:

>=1920HZ

Pixel Density:

15625

Control System:

LSN/NoVa

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

led full color screen

indoor led display screen

Product Description

China HD Outdoor P8 SMD Full Color LED Advertising Billboard for Shopping Mall Square

Product Specifications

Pixel pitch	8mm
Tube Chip Color	Full color
Waterproof	IP65
Cabinet material	Iron or Aluminum For Options
Frame Frequency	>=60HZ
Average NO Failure	>=1000hours
Transmitting distance	Internet cable <100m
Refresh Rate	>=1920HZ
Pixel Density	15625
Control System	LSN/NoVa

Product Features

Ultra-high brightness LEDs with high-quality plastic components
High-contrast hue for excellent display quality
Lightweight design for easy installation and removal
Single-point, single lamp maintenance capability with low cost
Constant current LED driving for uniform lighting and low power consumption
6mm pixel pitch with 32×16 pixel configuration (1R1G1B per pixel)

Key Advantages

High brightness (>4000cd/㎡) suitable for all-day outdoor use
Long lifespan exceeding 100,000 hours
Wide viewing angles (160° indoor, 120° outdoor)
Intelligent control system with computer or WiFi operation
Flexible shaping and seamless splicing compared to LCD displays

Technical Parameters

Pixel pitch(mm)	8mm
LED Type	SMD 3535/2727
Pixel composition	1R1G1B
Scan method	1/4
Screen brightness(cd/sqm,nit)	>6500nits (adjustable)
Average power consumption(W/sqm)	280
Maximum power consumption(W/sqm)	850
Module resolution(dot)	32dots×16 dots
Module size(mm)	256mm×128mm
Pixel density(dots/sqm)	15625dots
Viewing distance(m)	8-150m
Pixel weight	350g
Pixel power(max)	16 W/PCS
Visual range	>8 m
Grey Grade	>=10 BIT
Color temperature	11000±500K
Viewing angle	Level: 105° vertical: 50°
Life span	>50,000hours
Working temperature	-10°C to +50°C

Product Benefits

Wind-resistant structure (100 km/h) and earthquake-proof (8 magnitude)
Excellent waterproof performance with safe, reliable power system
Customizable components to meet specific requirements
Environmentally friendly materials throughout
Minimum 5-year product lifespan
2-5 year warranty coverage
Additional installation, technical support, and training services available

Packing & Shipping

Packing options: wooden case or flight case available.

Shipping methods: by air, sea, train, or DHL - customer's choice.

Frequently Asked Questions

How can I place an order?

Please provide detailed requirements for immediate quotation. For design discussions, contact us via Skype, email, or WhatsApp to avoid delays.

What kind of displays do you provide?

We offer indoor, outdoor, mobile, rental, stage, and advertising LED displays with customization options.

What is the lead time for orders?

Typically 7-17 days after payment confirmation. Some items may ship within 7 days if in stock.

What warranty do you offer?

2-5 year quality guarantee covering LED modules, receiving cards, control cards, and power supplies against non-artificial damage.

How do you ensure product quality?

All LED products undergo 72-hour testing before shipping with strict quality control at every production stage.

Do you provide technical support?

We offer free training on screen setup, parameter configuration, and video broadcasting using Nova Star, Colorlight, or Linsn control systems.
