P2.5 Indoor Full Color LED Video Wall Screen SMD2121 160000 Pixels/M²

Name: P2.5 Indoor Full Color LED Video Wall Screen SMD2121 160000 Pixels/M²
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P2.5
Price: 10000 USD
Availability: InStock

Brand Name:	SCXK
Model Number:	P2.5
MOQ:	5 pcs
Price:	negotiation
Payment Terms:	T/T,Western Union
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen in China

Certification:

CE/ROHS/FCC/ISO/CB

Pixels:

2.5mm

Led Type:

SMD2121

Cabinet:

Iron Or Aluminum For Options

MBI:

5124

Viewing Angle:

H:160 V:140

Optimal Viewing Distance:

>=2.5m

Voltage:

DC5V

Brightness:

1000cd/㎡

LED Parameter:

R:625-630nm

Driving Mode:

1/16 Scan

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

outdoor advertising led display

advertising led billboard

Product Description

LED Video TV Wall P3.91 Indoor Full Color Clear Digital Signage Displays P2.5 4K LED Panels

Product Specifications

Attribute	Value
Pixels	2.5mm
Led Type	SMD2121
Cabinet	Iron or Aluminum For Options
MBI	5124
Viewing Angle	H:160 V:140
Optimal Viewing Distance	>=2.5m
Voltage	DC5V
Brightness	1000cd/㎡
LED Parameter	R:625-630nm
Driving Mode	1/16 scan

Product Description

High Definition P2.5 320*160mm Indoor LED Advertising Video Wall Screen

Our Advantages

Professional Manufacturer of LED display

OEM service, No MOQ

Easy installation, regular items in Stocks

Offering free design drawing as requested

Remote controlling and adjusting are available

Wooden case or flight case options available

Fast response within 24 hours

Fast delivery: Usually 6-8 working days

Excellent R&D team, factory price with quality assurance

High Reliability

The products adopt static scanning technology and module design technology for higher reliability and stability.

Diversified Display Modes

Supports multiple display modes for versatile applications.

Detailed Technical Specifications

Indoor SMD P2.5
Lamp size	2121
Resolution/mm	2.5
Pixel configuration	RGB 3 in 1
Pixel density/pixels/m²	160000/m²
Module resolution	64x32
Module size/mm	160x160
View distance	≥1m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>2500cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 14 bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable: 100m, multimembrane:500m, monofilm:5km
Driving mode	Constant driving current
Scanning mode	1/32
Frame rate	60Hz
Refresh frequency	>4200Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡	<1100W
Average power:/㎡	<280W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment	WindowsNT, Windows1999, WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof, dustproof, high temperature protection, anti-corrosion, anti-burning, anti-static, anti-vibration
Humidity(working)	working: 10-95%
Humidity(storing)	storing: 10-95%

Product Overview

Items	Description
Indoor LED display	P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P10
Outdoor LED display	P3, P3.91, P4, P4.81, P5, P6, P8, P10, P12, P16, P20
Material	steel, aluminum, die casting aluminum
Payment terms	30% deposit before production, 70% balance before shipping
Packing	Standard Export Carton with fully Polyfoam or Pearl Wool Flight case Anti-shaking wooden case
Shipping	5 to 7 working days upon receiving deposit payment
After-Sales-Service	Lifetime with professional engineer support for free. Within 5 year, supply spare parts for free if has quality problem (not by man-made damage)
Using Range	Shopping mall, bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi, and more

Why Choose Us

Continuous Quality

With over 10 years experience in LED display production and regularly updated equipment, our standardized module production ensures consistent product quality.

Competitive Price

Our large-scale production capacity and professional technology allow us to offer factory-direct prices while maintaining high quality standards.

Fast Delivery

We prioritize meeting delivery deadlines, using emergency inventory procedures when necessary to ensure uninterrupted supply.

Perfect Service

Pre-sales: We carefully assess your requirements and recommend suitable products.
After-sales: We track product usage to continuously improve our offerings.

Packing & Shipping

Wooden case or flight case packaging available.
Shipping options include sea, air or DHL express.
