Place of Origin: | China |
Brand Name: | SCXK |
Certification: | CE,ROHS ,FCC,UL |
Model Number: | P3 |
Minimum Order Quantity: | 1sqm can be available |
---|---|
Price: | negotiation |
Packaging Details: | wooden box,paper box,flight case |
Delivery Time: | within 5-8 working days |
Payment Terms: | L/C, T/T, Western Union |
Material: | Super Thin Cabinet | Color: | Full Color |
---|---|---|---|
Pixel Density: | 111111/sqm | Application: | Indoor Fixed Stage Rental Usage |
Warranty: | 3 Years | Module Size: | 192mm X192mm |
Brightness: | 2500nits | Name: | P3 Indoor Smd Led Screen |
Use: | Advertising Publish, Shopping Mall, Welcome Display, Restaurant & Hotel Supplies | Specification: | Stretch Bar, Led Video Processor |
Place Of Origin: | Guangdong China | ||
Highlight: | indoor led display screen,indoor led billboard |
P3 indoor smd full color smd led display iron and steel cabinet for fixed usage
The parameter of the indoor P3 led display
LED Lamps | Type | SMD2121 (High Brightness LEDs) | |||||||
LED Standard | Real Pixel(1R1G1B) | ||||||||
Red Wavelength | 625-630nm | ||||||||
Green Wavelength | 515-530nm | ||||||||
Blue Wavelength | 465-475nm | ||||||||
LED Module | Pixel Pitch | 3mm | |||||||
Module Size | 192mm x192mm | ||||||||
Module Resolution | 64dots x 64dots | ||||||||
LED Cabinet | Cabinet Size | 576mm x576mm | |||||||
Cabinet Resolution | 192pixels *192pixels | ||||||||
Cabinets Material | Sealed Iron Cabinet | ||||||||
LED screen | Pixel Density | 111111pixels/sqm | |||||||
Drive IC | MBI5024 | ||||||||
Power Supply | Series connection | ||||||||
Brightness | 2500cd/sqm | ||||||||
Display Color | 16.7million | ||||||||
Viewing Angle | 160°(Horizontal),110°(Vertical) | ||||||||
Best Viewing Distance | 3m~200m | ||||||||
Max Power Consumption | 600 w/sq.m |
SCXK has been specialized in LED field since 2005. We are a leading manufacturer an provider of technical solution of full color indoor and outdoor led display,rental LED display, led modules where in Shenzhen city Guang dong province,China
We adopt the Taiwan epistar chip,National star,king-star light .and all kinds of the customed light,it’s more high definition and brightness( we still provide the led display module and spare parts to you,you can assemble it in your country.It can help you save shipment cost and custom fee) ( the iron and steel cabinet led display is very cheaper and cost-effective. very safe ,good for fixed usage .we still print your logo on it)
Our advantage:
1)Manufacturer with over 11 years experience in electronic goods & PCB assembly.
2)over 400 employees.
3)6 high-speed Panasonic SMT machine, 6 Yamaha SMT machine, 2 AOI testing equipment, etc.
4)10 production lines.
5)6S management.
6)Passed ISO9001:2008 & ISO14001:2004 and CE/RoHS/FCC certified
Application.
Stage,Sports,advertising,traffic,events,stadium,shopping center,airport,exhibitions, car shows,
fashion shows, concerts, ceremonies, entertainment,etc.
♦ Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our product
FAQ
Q1. What's the warranty of your LED Display Screen ?
A1. We have a 3-years warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2. What about your pre-sale service and post-sale service?
A2. For pre-sale service. We have a professional sales team and a 8 years technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!
For post-sale service. We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.
Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!
Q3. Whats your payment term? How long it takes to delivery?
A3. We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.Our average Production time is 10 days, after receiving the deposit.
Q4. What's the control system?
A4. For synchronization control. We use Nova, Linsn Or Colorlight control system.
For asynchronous control We use Onbon, or Xixun control system
