Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P10.42 |
| Minimum Order Quantity: | 1-1000sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T |
| Pixel Density: | 9216 Pixels/sqm | Brightness: | 6,000 Nits |
|---|---|---|---|
| Control System: | LNS | Cabinet Size: | 1000*1000 |
| Driver Mode: | 1/3 | Operation Power: | 220V 60HZ |
| Display Color: | 1.07 Billion | Refresh Rate: | 4000 Hz |
| High Light: | transparent led panel,transparent led display |
||
Product Features:
Free Radian Conjuction
2 Sets of radian locators make it possible to present image in concave and corivex shape at customized radians.
Ultra Thin and Light Weight
9KG/cabinet makes it easy to carry and assemble.
Status Indicator
Status indicator on backcover lets you know the working status of led cabinet without opening backcover
Strengthening Ribs
The ribs effectively strengthens the construction of cabinet frame,and also can be used as the carry handle.
Technical traits of P10.42 mm outdoor sports/stadium led screen display:
Vivid and exact picture, minimum noise, advanced test equipment, support any pc operation system and play a variety of information like video, word, flash, music, clock, graph etc. LED DISPLAY Cabinet design for easy install and dismantle.
| Pixel pitch | 10.42mm | ||
| Brightness | 6,000 nits | ||
| Brightness adjusted | 100 grade by software, or Auto-optic | ||
| Color temperature | Could be adjusted by software | ||
| LED configuration | 1R, 1G, 1B SMD | ||
| Pixel density | 9216 pixels/sqm | ||
| 2,304 pixels/cabinet (48 * 48) | |||
| Hor.viewing angle | 140 (min 50% brightness) | ||
| Vert.viewing angle | 140 (min 50% brightness) | ||
| Lifetime | 100,000 hours to 50% of initial brightness | ||
| MTBF | 10,000 hours | ||
| Power consumption | 800 w/sqm (Max) | ||
| 400 w/sqm (Average) | |||
| Operation power voltage | AC 110V / 50 - 60Hz | ||
| AC 220V / 50 - 60Hz | |||
| AC 100-240V / 50-60Hz | |||
| Working voltage | DC +5V | ||
| Cabinet dimensions | Width: 500mm | ||
| Height: 500mm | |||
| Depth: 75mm | |||
| Weight bearing | 1000 Kg/m2 | ||
| IP rating | IP65 Front side | ||
| IP55 Back side | |||
| Processing | 16 bit/color | ||
| Colors | 280 trillion | ||
| Refresh rate | 4000 Hz | ||
| Frame rate | 60Hz | ||
| Link interface | DVI | ||
| Operating temperature | -20℃ ~ +50℃ (-4° ~ 122°F) | ||
| Storage temperature | -35℃ ~ +85℃ (-31° ~ 185°F) | ||
| Operational humidity | 10-99% | ||
| Source compatibility | DVI,SDSDI,HDSDI,VGA,HDMI,YPbPr,PAL/NTSC system composite | ||
| Operatable digitizer | JSEE | ||
| Certifications | CE,FCC,RoHS | ||
Packaging:
1:Flight Case(5 cabinets in one case)
Gross Weight:150KG
Size:1010mm*560mm*1175mm
2:Wooden case(5 cabinets in one case)
Gross Weight:180KG
Size:1120mm*585mm*930mm
Buying Guides
In order to offer you a suitable solution,pleasefollow the guides belowing:
1, star effect or video effect which you need.
2,Dimension (Width and Height)
3,Location of installation. (picture is best)
4,Purpose. ( what are you going to do with the LED Curtain)
After-Sale Service
1. One year warranty , Lifetime free maintenance.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on
6. Special service for big project, such as stadium, exhibitions, squares and so on.
Company Information
Shenzhen SCXK Electronics Co.,Ltd has the standard new factory,and about 100 employees.
We have outstanding R&D department and after-sell service workers,and separately design ability.
Our product mainly included led single dual color display,led indoor full color display;led outdoor full color display,led wireless car used screen etc.It can be used on the shopping more,bank,bus station,train station,Center of downtown,airport,school,factory,bus,taxi and son on.
We adapt many methods and very good after-sell service to sell our product all over the world.
Whenever and wherever we are,we always take the principle that is:professional makes good quality,good price product market to provide perfect product and service for our customers.
Certifications:
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3. 36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
