Fixed Pitch 2.5mm LED Video Wall Panel, Church Giant Smd Full Color Indoor Advertising

Brand Name:	SCX
Model Number:	SCX-P2.5
MOQ:	1 sqm
Price:	450- 660 usd per sqm
Payment Terms:	L/C,, T/T,, Western Union,, MoneyGram
Supply Ability:	3000 square meters per month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE,ROHS,FC,UL

Module Dimension:

160mmx160mm

Module Resolution:

64×64

Driving Mode:

1/16

Brightness:

≥1200 Cd

Number Of Colors:

16.7 Trillion

Brightness Adjustment:

0-100% 8 Levels

Viewing Angle:

Horizontal 140° Vertical 120°

Min. Viewing Distance:

≥2.5 Meter

Gray Scale:

16384

Input Voltage:

AC220V/50Hz Or AC110V/60Hz

Packaging Details:

Flight Case

Highlight:

led video screen rental

rental led display screen

Product Description

Fixed Pitch LED Video Wall Panel Price Church Pantalla Giant Smd Full Color Indoor Advertising LED Screen P2.5

Advertising Led Screen Features

High brightness for great viewing
Ultra-low energy consumption
High refresh rate
Portable, easy to install and remove
All our LED signs come with a free 3-year limited warranty
Our full-color digital LED signs allow you to create your own unique messages and promotions
Customers have seen a 150% increase in sales after purchasing our scrolling LED signs

Advertising LED Screen Parameters

Pixel Pitch(mm)	2.5 mm
Pixel Configuration	SMD 2020
Pixel Matrix per Panel(dots)	192 x 192 dots
Pixel Density(dots/m²)	160,000 dots/m²
Cabinet Size(mm)	480 x 480 x 63mm
Panel Dimension(W×H×D)	( 18.9”×18.9”×2.5”)
Panel Material	Die-casting Aluminum
Panel Weight(kg/panel)	5.1 kg/panel (12.3 lb/panel )
Color Depth(Bit)	14 bit
Refresh Rate(Hz)	≥2880Hz
Driver Method/scan	Scan 1/32
Brightness(nits)	1000nits, adjustable
Horizontal Viewing Angle(°)	160 °
Vertical Viewing Angle(°)	160 °
AC Power Input(V)	AC110V~ 220V ±10%
AC Power Frequency(Hz)	50 ~ 60 Hz
Max. Power(W/m²)	520 W/m²
Avg. Power(W/m²)	170 W/m²
Storage/Operating Humidity(RH )	10% ~ 90%RH
IP Rating(IP )	IP30 / IP30
Lifetime Typical Value(Hrs)	100,000 Hrs
Installation Type	Fix , Front installation
Maintenance Method	Front & Rear serviceable
Certifications	CE, Rohs, FCC, TUV-CE,ETL

Advertising Led Screen Project

As our company SCX has 10 years history in the field of led display screen .

We export led wall to lots of countries, like USA, Canada,Mexico,Panama, Brazil

, UK, France,Germany, Netherlands , Norway ,Belgium , Italy, Malta, Monaco , Poland,Russia , Spain ,Sweden , Switzerland ,Ukraine ,Romania , South Africa, Kenya, India, Malaysia , Saudi Arabic, Austraila, Japan, Korea etc more than 50 countries .

Fixed Pitch 2.5mm LED Video Wall Panel, Church Giant Smd Full Color Indoor Advertising 0

Fixed Pitch 2.5mm LED Video Wall Panel, Church Giant Smd Full Color Indoor Advertising 1

FAQ

How to choose a proper led screen for your need?
You just need to think of 3 simple questions when you choose a led screen by yourself.

1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place for ever)
3.what is the appoximate size of the led screen you would like to purchase?

Which control system should i choose?
There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.
But asyn control system's refresh rate is much lower than sync control system.
And for asyn control system, you can choose to use wifi,3G,4G etc wireless control.

How to order from you compamy?
You can both place order to us by online or to our company directly offline, before place order welcome to contact us for confirmation.

How to pay?
We accept payment online through , or offline to our company account by T/T bank, Cash or paypal or westerunion.

How to ship?
It is optional and we respect customer's choice. You can choose to ship by air cargo, by DHL(Fedex,UPS etc) internation express company, or by sea according to your goods weight and volume and the delivery time you need.

How to install it after i received it?

We make sure to provide engineer to give guide of installation and set up of the display by e-mail,telephone and remote asistance.
