P3.91mm Indoor Full Color LED Video Wall Panel 5000cd Brightness IP65

Name: P3.91mm Indoor Full Color LED Video Wall Panel 5000cd Brightness IP65
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P3.91
Price: 10000 USD
Availability: InStock

Brand Name:	SCXK
Model Number:	P3.91
MOQ:	1 pcs
Price:	negotiation
Payment Terms:	T/T,Western Union
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen in China

Certification:

CE/ROHS/FCC/ISO/CB/UL

Pixels:

3.91mm

Tube Chip Color:

Full Color

Led Type:

SMD2121

Waterproof:

IP65

MBI:

5124

Viewing Angle:

H:160 V:140

Voltage:

DC5V

Brightness:

5000cd/㎡

LED Parameter:

R:625-630nm

Module Size:

250*250MM

Screen Size:

500*500MM

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

led video screen rental

led rental screen

Product Description

HD P3.91 Stage Background Design LED TV Studio Screen/Indoor LED Video Wall Panel Screen

Technical Parameters

Product Model	P2	P2.5	P3	P3.91	P4	P5	P6
Pixel Pitch	2mm	2.5mm	3mm	3.91mm	4mm	5mm	6mm
Driving Mode	1/32 Scan	1/32 Scan	1/32 Scan	1/32 Scan	1/16 Scan	1/16 Scan	1/16 Scan
Pixel Configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
LED Type	SMD 1515 Black	SMD 2020 Black	SMD 2020 Black	SMD 2020 Black	SMD 2020 Black	SMD 2020 Black	SMD 3528 Black
Module Size(mm)	256*256	240*240	192*192	250*250	128*128	320*160	192*192
Module Pixels	128*128	96*96	64*64	64*64	32*32	64*32	32*32
Pixel Density	250000 dots/sqm	160000 dots/sqm	111111 dots/sqm	65536 dots/sqm	62500 dots/sqm	40000 dots/sqm	27777 dots/sqm
Viewing Angle	140°/120°	140°/120°	140°/120°	140°/120°	140°/120°	140°/120°	140°/120°
Max./Avg. Power Consumption	1000/400 W/sqm	1000/400 W/sqm	900/360 W/sqm	800/320 W/sqm	800/320 W/sqm	600/240 W/sqm	600/240 W/sqm
Brightness	≥1800 cd/m²	≥1500 cd/m²	≥1500 cd/m²	≥1500 cd/m²	≥1500 cd/m²	≥1500 cd/m²	≥1200 cd/m²
Refresh Rate	≥3000Hz	≥2000Hz	≥2000Hz	≥2000Hz	≥2000Hz	≥2000Hz	≥2000Hz
Recommended Viewing Distance	≥2m	≥2.5m	≥3m	≥3.91m	≥4m	≥5m	≥6m
Operating Temperature/Humidity	-20℃~+65℃/10%~95%RH

Features of P3.91 / 4.81 LED Screen

500mm*1000mm light weight cabinet (15kgs sample design)
Uses printed circuit board instead of metal cables in cabinet sides
Eliminates complex cable checking and connection
Ensures smooth display operation
Simplifies maintenance - faulty circuit boards can be easily replaced

Installation Instructions

Production Process

Incoming Inspection
SMD
Plug-in
Wave Soldering
After Welding
Testing
Semi Finished Aging
Module Assembly
Gluing
Finished Aging
Detection Finishing Warehousing

Packaging and Shipping

Wooden case or flight case package
Shipping by sea, air or DHL

Why Choose Us

Continuous Quality

With over 10 years of LED display production experience, we regularly update equipment and maintain standardized module production for consistent quality.

Competitive Price

Our large-scale production capacity and professional technology enable cost-effective solutions without compromising quality.

Fast Delivery

We honor delivery commitments and implement special procedures like emergency inventory to ensure uninterrupted supply.

Perfect Service

Pre-sales: We carefully evaluate requirements and recommend suitable products. After-sales: We track product usage to continuously improve our offerings.

Our team is committed to providing you with full support!
