P4 Outdoor Magic Special Shape Stage LED Screens Wifi Control with CE UL

P4 Outdoor Magic Special Shape Stage LED Screens Wifi Control with CE UL

    • P4 Outdoor Magic Special Shape Stage LED Screens Wifi Control with CE UL
    • P4 Outdoor Magic Special Shape Stage LED Screens Wifi Control with CE UL
    • P4 Outdoor Magic Special Shape Stage LED Screens Wifi Control with CE UL
  • P4 Outdoor Magic Special Shape Stage LED Screens Wifi Control with CE UL

    Product Details:

    Place of Origin: China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: p4

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Product Name: P4 Outdoor Magic Special Shape Stage LED Screens Wifi Control With CE UL Brightness: Above 8000cd/㎡
    Usage: Stage, Events, And So On Protective Degree: IP65
    Screen Gray Scale: 16bits Per Color Screen Dimension: Customized Size
    High Light:

    led stage display

    ,

    stage led display

    P4 Outdoor Magic Special Shape Stage LED Screens Wifi Control with CE UL



    Quick details

    1.Creative, unique shape ,shaping freely

    2.LED 3D sound control cheap video wall, effect clear and beautiful.

    3.Flexible combination installation,unique and creative design.

    4.Humanization design :power&control system integrated,fast locker design

    5.Light and audio synchronously control,3D fantastic effect.



    Our advantages

    1) We're a professional manufacturer with 15 years experience

    2) Large-scale production line ,high supply ability

    3) Advance equipment, the quality are excellent

    4) Our high quality goods,after sale service have enjoyed great popularity among our clients



    ♦ Technical specification



    outdoor  SMD P4
    Resolution 4mm
    Pixel configuration 1R1G1B
    Pixel density/pixels/m² 62500/m²
    Module resolution 64x32
    Module size/mm 256x128
    View distance 3-300m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >8000cd/㎡
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 60(degrees)
    Signal Process bit 10 or 16bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
    Driving mode Constant driving current
    Scanning mode (1/4)
    Frame rate 60Hz
    Refresh frequency >3000Hz
    Control mode Computer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted

    255 steps. No grey loss

    Out of control point <1/10000
    Working hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃
    Maximum power:/㎡ <1000W
    Average power:/㎡ <350W
    Self-check technology

    LED spot self-check, communications check, power check,

    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,

    send out warning signs to the operators.(need customization)

    Software environment WindowsNT,Windows1999,WindowsXP
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast  (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%



    Product overviews
    Items Indoor Led display:
    P1.5 P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10
    Outdoor Led display:
    P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
    Dance floor led display
    DJ led screen
    Transparent led display
    Material steel,aluminum ,die casting aluminum
    Certificates CE, FCC,RoHS, CCC, UL
    Payment
    terms
    30% deposit before production, 70% balance before shipping
    T/T
    Western Union
    Packing: Standard Export Carton with fully Polyfoam or Pearl Wool
    Flight case;
    Anti-shaking wooden case
    Shipping: 5 to 7 working days upon receiving deposit payment
    After-Sales-Service: Lifetime with professional engineer support for free.
    Within 5 year, supply spare parts for free if has quality problem
    ( not by man-made damage)
    Using Range Shopping mall,bank,bus station, train station,
    center of downtown, airport, school, factory, bus, taxi,and so on.



    ♦ Production process



    1) Incoming Inspection→2)SMD→3)Plug-in

    →4) Wave Soldering→5)After Welding→6)Testing

    →7) Semi Finished Aging→8)Module Assembly

    →9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing



    ♦ Packaging



    Wooden case

    flight case package
