Fine Pitch P2 Full Color Indoor LED Display Panel 250000px/M² 600W Power

Fine Pitch P2 Full Color Indoor LED Display Panel 250000px/M² 600W Power

Brand Name:	SCXK
Model Number:	P2
MOQ:	2 sqm
Price:	negotiation
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	5000 sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen China

Certification:

CE/ROHS/FCC/ISO/CB/UL

Pixels:

2mm

Tube Chip Color:

Full Color

Display Function:

Video/Text/Image

Cabinet:

Die-casting Aluminum

Frame Frequency:

>=60HZ

Average NO Failure:

>=1000hours

Transmiiting Distance:

Internet Cable <100m

Refresh Rate:

>=1920HZ

Maximum Power:

600m2

Optimal Viewing Distance:

>=2m

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

led video screen rental

rental led display screen

Product Description

4K Clear Interior P2 Mega Stage Background Trade Show Video Wall Screen Full Color LED Display Panels

4K Clear P2 Mega Stage Background Trade Show Video Wall Screen Full Color LED Display Panels for Indoor Usage

Product Specification

Specification	Details
Lamp size	1515
Resolution/mm	2
Pixel configuration	RGB 3 in 1
Pixel density/pixels/m²	250000/m²
Module resolution	160x80
Module size/mm	320x160
View distance	≥2m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>1000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 14 bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode	Constant driving current
Scanning mode	1/40
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡	<1100W
Average power:/㎡	<380W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Product Features

Waterproof
Dustproof
Moisture proof
Anti-collision
Anti-UV
Prevents LEDs from falling off

About Us

Established in 2005, our clients cover more than 50 countries including USA, Europe, Dubai, North and Mid America, South America, and Asia. As a high-tech enterprise integrated with scientific research, design, production, maintenance, sales and system integration, we have:

Professional high-quality technical R&D team
Experienced engineers and product development specialists
Excellent marketing team
24-hour pre and after-sales service

We carefully select materials to create optimal solutions for even the harshest environments.

Production Process

Incoming Inspection
SMD
Plug-in
Wave Soldering
After Welding
Testing
Semi Finished Aging
Module Assembly
Gluing
Finished Aging
Detection Finishing Warehousing

Packaging and Shipping

Wooden case or flight case package available. Shipping options include sea, air or DHL.

Why Choose Us

Continuous Quality

With over 10 years of LED display production experience, we regularly update equipment and maintain unique standardized module production to ensure consistent product quality.

Competitive Price

Our large-scale production capacity and professional technology enable us to offer cost-effective solutions while maintaining technical innovation.

Fast Delivery

We honor delivery commitments and implement special procedures like emergency inventory to maintain uninterrupted supply.

Perfect Service

Pre-sales: We carefully evaluate requirements and recommend suitable products.
After-sales: We track product usage to continuously improve our offerings.
