P3 Indoor Stage Church Full Use Color LED Display 192x192mm 3mm Pixel

Brand Name:	SCXK
Model Number:	P3
MOQ:	2 sqm
Price:	negotiation
Payment Terms:	Western Union,MoneyGram,D/P,T/T,L/C
Supply Ability:	5000 sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen in China

Certification:

CE/ROHS/FCC/ISO/UL/CB

Pixels:

3mm

Tube Chip Color:

Full Color

Display Function:

Video

Cabinet:

Iron Or Die-casting Aluminum

Pixel Configuration:

1R1G1B

Warranty:

3 Years

Brand:

SCXK

Voltage:

DC5V

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

led full color screen

indoor led billboard

Product Description

RGB Indoor Full Color LED Display Video Processor P3 High Brightness LED Screen Module

Advertising HD P3 Indoor Full Color LED Display SMD Die Casting Aluminum

Product Specification

Indoor SMD P3
Lamp size	2121
Resolution/mm	3
Pixel configuration	RGB 3 in 1
Pixel density/pixels/m²	111111/m²
Module resolution	64x64
Module size/mm	192x192mm
View distance	≥3m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>1000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 14 bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode	Constant driving current
Scanning mode	1/8
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡	<900W
Average power:/㎡	<300W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment	WindowsNT, Windows1999, WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof, dustproof, high temperature protection, anti-corrosion, anti-burning, anti-static, anti-vibration
Humidity(working)	working: 10-95%
Humidity(storing)	storing: 10-95%

Advantages

Natural Heat Dissipation (no cooling system needed)
360 degree rotation
Stunning Visual Experience
High recall rate and attracting customers

Product Description

This high-performance LED display is specially designed for indoor or outdoor column facades, available in both cylinder and square shapes. The 360-degree viewing angle provides a perfect visual experience from any perspective.

Front service access makes maintenance easy when needed. Ideal for urban development projects and architectural enhancements.

For square LED screens, we can customize any pixel pitch according to your project requirements, with group control for easy operation.

Packaging and Shipping

Available in wooden cases or flight cases. Shipping options include sea, air or DHL with multiple shipping methods to choose from.

Why Choose Us

Continuous Quality

With over 10 years of experience in LED display production and regularly updated equipment, our standardized modular production ensures consistent product quality.

Competitive Price

Our large-scale production capacity and professional technology enable effective modular production. We continuously innovate to reduce costs and benefit our customers.

Fast Delivery

We honor our delivery commitments and implement special procedures like emergency inventory to maintain uninterrupted supply.

Perfect Service

Pre-sales: We carefully evaluate your requirements and recommend suitable products.
After-sales: We track product usage to continuously improve our offerings.
