Fine Pitch P2 Indoor Full Color LED Display 2mm Pixel 1000cd Brightness

Brand Name:	SCXK
Model Number:	P2
MOQ:	3 pcs
Price:	negotiation
Payment Terms:	Western Union, MoneyGram, D/P, T/T, L/C
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen in China

Certification:

CE/ROHS/FCC/ISO/UL/CB

Pixels:

2mm

Led Type:

SMD2727

Waterproof:

Ip43

Cabinet:

Die Catsing Aluminum/iron

MBI:

5124

Viewing Angle:

H:100 V:50

Voltage:

DC5V

Brightness:

1000cd/㎡

LED Parameter:

R:625-630nm

Module:

320*160mm

Cabinet:

640*640mm

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

indoor led display screen

indoor led billboard

Product Description

Fine Pitch Ultra Thin P2 Indoor Full Color LED Display Screen For Wedding Halls

Ultra Thin SMD 3 In 1 Indoor Full Color LED Display Screen For Wedding Halls

Product Specification

Specification	Details
Lamp size	2121
Resolution/mm	2
Pixel configuration	RGB 3 in 1
Pixel density/pixels/m²	250000/m²
Module resolution	128x64
Module size/mm	256x128
View distance	≥2m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>800cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 14 bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable: 100m, multimembrane: 500m, monofilm: 5km
Driving mode	Constant driving current
Scanning mode	1/40
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡	<1000W
Average power:/㎡	<300W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment	WindowsNT, Windows1999, WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof, dustproof, high temperature protection, anti-corrosion, anti-burning, anti-static, anti-vibration
Humidity(working)	working: 10-95%
Humidity(storing)	storing: 10-95%

Advantages

1. Natural Heat Dissipation (no cooling system needed)

2. 360 degree rotation

3. Stunning Visual Experience

4. High recall rate and attracting customers

Product Description

This indoor/outdoor LED display is specially designed for column facades, available in both cylinder and square shapes. The 360-degree viewing angle provides a perfect visual experience.

Front service design makes maintenance easy when needed. Ideal for urban development projects requiring high-quality displays.

Square LED screens can be customized to any pixel pitch according to project requirements, with group control for easy operation.

Packaging and Shipping

Available in wooden cases or flight cases. Multiple shipping options including sea, air, or DHL.

Why Choose Us

Continuous Quality

With over 10 years of LED display manufacturing experience, we regularly update equipment and maintain standardized module production for consistent quality.

Competitive Price

Our large-scale production capacity and professional technology enable cost-effective solutions without compromising quality.

Fast Delivery

We prioritize meeting promised delivery dates, implementing emergency inventory procedures when necessary.

Perfect Service

Pre-sales: We carefully assess requirements and recommend suitable products.
After-sales: We track product usage to continuously improve our offerings.
