Place of Origin: | China ,Guang Dong |
Brand Name: | Shichuangxinke |
Certification: | CE RoHS FCC CCC TUV UL |
Model Number: | SCXK-P3.91 |
Minimum Order Quantity: | 3 square meters |
---|---|
Price: | USD 1000-2700 per square meters |
Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
Delivery Time: | 7-10 working days after deposit payment received |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 5000sqm per month |
Resolution/mm: | 3.91 | Pixel Configuration: | 1R1G1B |
---|---|---|---|
Scanning Mode: | 1/8 Scanning | Module Size: | 250x250MM |
Cabinet Size: | 500x1000MM | Certificates: | CE RoHS FCC CCC UL |
Material: | Aluminum/Iron | Warranty: | 3-5 Years |
Application: | Stadium,airport,shopping Mall,street Advertising | ||
Highlight: | led display rgb,rgb led screen |
HD 1/8 scanning rgb led screen wall P3.91 , Outdoor SMD LED Display Billboard
Features:
1. Aluminum alloy structure, good heat dissipation performance, with heat dissipation holes, high hardness
2. The cabinet is small in size, light in weight, easy to carry and install
3. High resolution, 65410 dots/㎡, good color uniformity
4. Each panel has two positioning rods, supporting hoisting and rental activities
Product Description:
1. High color contrast and consistency, high brightness ensures good display effect.
2. The cabinet adopts CNC technology, and the flatness between cabinet units is <0.2mm.
3. Energy-saving and noiseless power supply, good heat dissipation performance, ensure good stability and service life.
4. Constant current drive, brightness attenuation <5%/year.
Shenzhen Saikexing Technology Co., Ltd. is a high-tech company specializing in the production and sales of LED display screens, digital signage and other advertising multimedia products research and development, production and sales, committed to providing electronic information engineering solutions and the development and application of various information release systems. At present, the company's LED large-screen products are widely used in outdoor advertising media, cultural and entertainment activities, stadiums, stage rentals, etc. With the advantages of the full-color LED display system, from design, production, installation, maintenance, a full range of integrated solutions are adopted to effectively reduce customer costs, thereby creating higher value for customers.
Specifications :
outdoor DIP P10 | |||||
Resolution/mm | 3.91 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 65410/m² | ||||
Module resolution | 64x64 | ||||
Module size/mm | 250x250MM | ||||
View distance | 14-300m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | >7500cd/㎡ | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/8 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | >3000Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
Applications
Outdoor Full Color LED Display Are Very Popular In Advertising Field.
This Type Screen Are Popular Used Outdoor Shopping Center,Outdoor Building,Foodball Field,crossroad,
highway,Concert,airport etc;
Shipping Detail:
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
FAQ:
Q1,How to arrange payment?
Our payment terms in usually is T/T payment,for sample and small order,Western union,Paypal or Moneygram also be acceptable
Q2,What is our warranty?
Our warranty from 5year to 1year basis on different type led screen,In usually every screen we will ready more extra led screen moduless as spare modules,if some modules happen fails,you can replace the fail modules by our spare modules,When all the spare modules use out,You can send back these modules to us for repair,and we will send to you after repair and testing&aging well
Q3,How to be our distributor?
To be our distributor,We can share our profit together with you in every year,Also we can send our engieer or sales to your compay to support your business,also for led screen after-service,We will together with you to the after-service in the whole led screen life time
Q4, How to maintence led screen?
In usually every year to maintence led screen one time,clear the led mask,checking the cables connection,if any led screen modules fail,you can replace it with our spare modules
Our team will be forever here to offer you full supports !!!
