Place of Origin: | China |
Brand Name: | SCXK |
Certification: | CE,ROHS ,FCC,UL ISO2001 |
Model Number: | SCXK-P10 |
Minimum Order Quantity: | 1sqm can be available |
---|---|
Price: | negotiation |
Packaging Details: | the led display can be packaged with wooden box,paper box,flight case |
Delivery Time: | 7-10days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/P, D/A, L/C |
Supply Ability: | 1000sqm/month. we can make the led display on time |
Cabinet Size: | 960mmx960mm | Display Color: | 16.7million |
---|---|---|---|
Usage: | Video And Picture Usage | Drive Mode: | 1/4 Scaning |
Module Size: | 320mm X160mm | IP: | IP67 |
Color: | Full Color | Resolution: | 16x16 |
Control System: | Synchronization And A Synchronization | ||
Highlight: | rgb led screen,full color outdoor led display |
IP67 video 10000dots / qm RGB LED Display outdoor 960mmx960mm cabinet
Shenzhen shichuangxinke electronic co.,ltd,a manufacturer of all kinds of LED display,owing a factory of 5000m²,
and over 200 stuffs to reach an anual vaule beyond 50 million use,have more than 10 years export experience.
We mainly focus on big size full color led display,usually over 6m² per one screen,our application field include advertising,
stage,stadium,highway,hotel,shopping mall,traffic guiding...etc
Our main market is North America,South America and Europe.
Our full color outdoor led display parameter as follows.Please check it.
Product Parameters
Module Parameters | |||||
1 |
Pixel Pitch |
10mm | 5 | Module size(mm) | 320*160mm |
2 | Physical Density(dots/sqm) | 10000 | 6 | Module Resolution | 32*16 |
3 | LED Shape | SMD3535 | 7 | Drive Mode | 1/4 |
4 | LED Configuration | 1R1G1B | 8 | Operation Temperature | -20°C∼60°C |
Cabinet Parameters | |||||
1 | Cabinet Size | 960mmx960mm | 9 | Brightness | ≥6500nits |
2 | Cabinet resolution | 96*96dots | 10 | Average power consumption(w/m²) | 500 |
3 | Led Chip | Epistar(From Taiwan) | 11 | Max power consumption(w/m²) | 900 |
4 | Cabinet material | Steel | 12 | Refresh Rate(Hz/s) | ≥1920 |
5 | Viewing angle | 140H/120V | 13 | IP Rating | Front:IP65,Rear:IP54 |
6 | Color number | 281 trillion | 14 | Working Voltage | 220-380V±10%,47∼64Hz |
7 | Input Power | DC5V | 15 | Display Mode | Synchronous with video source |
8 | Screen Life Span | ≥10000hours | 16 | Signal Communication | DVI,RS232,LAN |
the outdoor full color led display module ( smd and dip are available) | |||||
Number | Drive mode | Moduel size | Resolution | Led standard | pixel density |
P4 | 1/8 scan | 256x128mm | 64x32 | 3in1 | 62500 |
p4.81 | 1/13scan | 250x250mm | 52x52 | 3in1 | 43222 |
p5 | 1/8 scan | 160x160mm | 32x32 | 3in1 | 40000 |
P6 | 1/8 scan | 192x192mm | 32x32 | 3in1 | 27778 |
P8 | 1/4scan | 256x128mm | 32x16 | 3in1 | 15625 |
P10 | 1/4scan | 160x160mm | 16x16 | 3in1 | 10000 |
P12 | 1/4scan | 192x192mm | 16x16 | 3in1 | 6944 |
P16 | static scan | 256x256mm | 16x16 | 3in1 | 3906 |
P20 | static scan | 320x160mm | 16x8 | 3in1 | 2500 |
P25 | static scan | 200x200mm | 8x8 | 3in1 | 1600 |
P31.25 | static scan | 250x250mm | 8x8 | 3in1 | 1024 |
1) High intensity and can be adjusted, so can meet the request of the customers according the application environment.
2) Best equality, have the excellent consistency of light.
3) To pictures and character, have clear, exquisite and real display effect.
5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.
Continue with the past and open up the future, shichuagnxinke will develop industry chain in horizontal and enrich the profit pattern.
High quality products need a powerful marketing distributing network to highlight its value,
we expect the partners all over the world to join our distributor team to make the business easier and fast.
Packing>>>
For iron cabinet led display screen of indoor or outdoor,we usually use wooden case to packing
For aluminum cabinet of led rental stage display,we usuallu use flight case to packing
One wooden case including 2 cabinets,one flight case including 6 cabinets
Shippment>>>
By air or sea,FOB shenzhen
UPS/DHL/Fedex/Express(door to door)and so on
Delivery time>>>
within 20 days counting from 30% prepayment arrived at Suyen account.
Payment term>>>
T/T(30% deposit,the remained 70% payment made before factory shipment )
Western union/paypal/L/C and so on
Quality assurance>>>
We offer 6 years warranty,and our products have passd CE,RoHS,FCC certificate ,All products have Age testing,s
haking testing,waterproof testing,In generally,Module test is 24h,entire screen test is 72h,A series of testing before delivery can ensure transportation and quality products.
