Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.

|
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE,ROHS ,FCC,UL ISO2001 |
| Model Number: | SCXK-P10 |
| Minimum Order Quantity: | 1sqm can be available |
|---|---|
| Price: | negotiation |
| Packaging Details: | the led display can be packaged with wooden box,paper box,flight case |
| Delivery Time: | 7-10days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram, D/P, D/A, L/C |
| Supply Ability: | 1000sqm/month. we can make the led display on time |
| Cabinet Size: | 640mmx640mm | Display Color: | 16.7million |
|---|---|---|---|
| Usage: | Video And Picture Usage | Drive Mode: | 1/4 Scan |
| Module Size: | 160mm X160mm | Color: | Full Color |
| Control System: | Synchronization And A Synchronization | Led Lamp: | DIP346 |
| Highlight: | led display rgb,full color outdoor led display |
||
P10 IP67 rgb led panel , Outdoor Advertising LED Display for fixing usage
Outdoor High Brightness advertising led display screen p10mm
1. High brightness which is adjustable to sufficiently meet the needs of various application environments.
2. The raw material of all of the outdoor products including LED chips, mask, glue and steel cabinets have the ability of enduring high temperature and high humidity, and being anti-UV, waterproof, anticorrosion and antirust.
3. Every production process is well controlled and all of the electronic components are covered by 2mm Tri-Guard Lacquer to ensure no oxidation, no rusty and no moisture. Five-Guard Lacquer will be used for special requirements.
4. Large viewing angle, up to 135°horizontally and 55°vertically, with no image distortion and no color cast at any angle within this range.
5. All of the cabinets are tested by flush, shower and soaking, to ensure the waterproof grade in front side to be IP67 and back side to be IP65,
and the Highway Display Screen is designed with double-deck door to ensure IP67 for both sides.
6. Good performance in color uniformity. The differences among LED chips in the same screen are no more than 3nm in wavelength,
1.2 times in brightness, 0.2V in power voltage, the waveform must be normal distribution and the color formation must be RGB:3:6:1 as required.
Product Parameters
| LED module specification | ||
| Module size | 320mm*160mm | 160x160mm |
| Pixel pitch | 10mm | 10mm |
| Pixels Density | 10,000 dots/m2 | 10,000 dots/m2 |
| Pixel configuration | 1R1G1B | 1R1G1B |
| Package mode | SMD3535 | DIP346 |
| Pixel resolution | 32dots(W)*16 dots(H) | 16dots(W)*16 dots(H) |
| Max Power | 20W | 18W |
| Module thickness | 17.05mm | 18.05MM |
| Weight | 0.37kg | 0.35KG |
| Drive type | Constant drive | Constant drive |
| Scan mode | 1/4can | 1/4can |
| Port type | HUB75-A | HUB75-A |
| Brightness of white balance | 6500cd/sqm | 7800cd/sqm |
| the outdoor full color led display module ( smd and dip are available) | |||||
| Number | Drive mode | Moduel size | Resolution | Led standard | pixel density |
| P4 | 1/8 scan | 256x128mm | 64x32 | 3in1 | 62500 |
| p4.81 | 1/13scan | 250x250mm | 52x52 | 3in1 | 43222 |
| p5 | 1/8 scan | 160x160mm | 32x32 | 3in1 | 40000 |
| P6 | 1/8 scan | 192x192mm | 32x32 | 3in1 | 27778 |
| P8 | 1/4scan | 256x128mm | 32x16 | 3in1 | 15625 |
| P10 | 1/4scan | 160x160mm | 16x16 | 3in1 | 10000 |
| P12 | 1/4scan | 192x192mm | 16x16 | 3in1 | 6944 |
| P16 | static scan | 256x256mm | 16x16 | 3in1 | 3906 |
| P20 | static scan | 320x160mm | 16x8 | 3in1 | 2500 |
| P25 | static scan | 200x200mm | 8x8 | 3in1 | 1600 |
| P31.25 | static scan | 250x250mm | 8x8 | 3in1 | 1024 |
Features:
Q1: What's the warranty of your LED Display Screen ?
A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2: What about your pre-sale service and post-sale service?
A2: For pre-sale service: We have a professional sales team and a 12 years technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.
Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!
Q3: Whats your payment term? How long it takes to delivery?
A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.
Our average Production time is 16 days, after receiving the deposit.
