P6 Outdoor Full Color LED Display SMD 6mm Pixel IP65 Waterproof

P6 Outdoor Full Color LED Display SMD 6mm Pixel IP65 Waterproof

Product Details:
Place of Origin: ShenZhen China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/CB
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: 5 sqm
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T,Western Union
Supply Ability: 5000 sqm per month
Contact Now
Detailed Product Description
Pixels: 6mm Tube Chip Color: Full Color
Cabinet: Steel Or Aluminum For Options Pixel Configuration: 1R1G1B
Warranty: 3 Years Brand: SCXK
Highlight:

led screen module

,

led sign module

Outdoor Full Color LED Screen P5 P6 P8 P10 Rear Service Customized Fixed Advertising Billboard
Product Attributes
Pixels 6mm
Tube Chip Color Full color
Cabinet Steel or Aluminum For Options
Pixel Configuration 1R1G1B
Warranty 3 years
Brand SCXK
SMD P5 P6 P8 Outdoor LED Advertising Display Screens Waterproof High Resolution
Key Features:
  • IP65 Level Waterproof
  • High Quality Power and Control Card
  • Standard cabinet size: 960mm*960mm, Depends the Display size
  • Highly effective & quick for transportation and screen assembling
  • SMD black light, wider viewing angle, high-contrast(5000:1), soft image
  • Special buckles structural connection between the cabinets, don't need other tools
  • Cabinets are in common use for standard modules, shorten production cycle
P6 Outdoor Full Color LED Display SMD 6mm Pixel IP65 Waterproof 0
Product Description

High Stability: Use high quality components and parts and sophisticated processing technique. Products with stable quality, high reliability and long life span.

Rich Content: It can show text, chart, graphic, cartoon, video and so on.

High Refresh Rate: Adopt MBI5124 drive IC (Standard Configuration). The refresh rate can be as high as 1920Hz, which can eliminate ghost effect effectively.

High Resolution: Adopt high pixel density display unit with micro pitch, which can joint the boards together in any direction, any size and any shape.

Superior Consistency: Adopt high quality black LED lamp with black cover. The contrast can be as high as 3000:1.

Super-wide view angle: 140° view angle and consistent display effect at multi direction, no mosaic phenomenon.

Advanced control system: Prefer adopting advanced and stable Nova Star control system.

LED Single-lamp maintenance with low cost.

Environmental-friendly and energy-saving.

P6 LED Display Module Technical Parameter (T=25 °C)
Technical Parameter Parameters Values
Pixel Pitch 6mm
Physical Density 62500dots
Pixel Configuration 1R1G1B
LED Parameter R: 82~102mcd ; 621~625nm
G: 245~305mcd; 524~528nm
B: 45~56mcd; 468~472nm
LED Encapsulation SMD 2121Black (Nationstar or Aplight LEDs)
Module Size 256*128mm
Module Resolution 64*32dots
Cabinet Size 768*768mm
Cabinet Resolution 192*192dots
Driving Method Constant Current
Scanning Mode 1/16 scan
Driving Device MBI 5124 IC (Standard Configuration) or other High refresh rate driver IC
Module Working Voltage DC 5V
Module Consumption 18W
Viewng Angle 140°
Frame Frequency ≥60Hz
Refresh Frequency ≥1920Hz
Equilibrium Brightness >1400cd/m2
Working Environment Temperature -10°C ~ 60°C
Working Environment Humidity 10% ~ 70% RH
Color Temperature ≥10000K
Gray Scale / Color ≥16.7M color
Mean Free Error Time >5000hours
Life Span >100000hours
Lamp Failure Frequency <0.0001
P6 Outdoor Full Color LED Display SMD 6mm Pixel IP65 Waterproof 1
Certifications

Our former product like transparent soft LED display have CE, FCC and Rhos certificate, our new foldable flexible LED module display will have EC certificate soon. Our product is compliant with every international standard.

P6 Outdoor Full Color LED Display SMD 6mm Pixel IP65 Waterproof 2
Packaging and Shipping

Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping ways for your choice.

P6 Outdoor Full Color LED Display SMD 6mm Pixel IP65 Waterproof 3
Why Choose Us

Continuous Quality: With more than 10 years experience in LED display production, equipments are updated regularly. Unique standardized and module production ensure our products continuous quality.

Competitive Price: With large scale production capacity and professional production technology, we have built effective modular production to reduce costs.

Fast Delivery: Once we promise the delivery date, we will try our best to fulfill it. Special procedures such as emergency inventory will be used to maintain your uninterrupted supply.

Perfect Service: Pre-sales: Your purchasing requirements will be highly valued. After-sales: We will track the products usage and constantly perfect our products.
