P10 Outdoor LED Advertising Screen 10mm Pixel Pitch IP65 Waterproof high brightness

P10 Outdoor LED Advertising Screen 10mm Pixel Pitch IP65 Waterproof high brightness

Brand Name:	SCXK
Model Number:	P10
MOQ:	1 pcs
Price:	negotiation
Payment Terms:	Western Union, MoneyGram, D/P, T/T, L/C
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen in China

Certification:

CE/ROHS/FCC/ISO/CB

Pixel Pitch:

10mm

Product Name:

Led Advertising Screen

Waterproof:

IP65

Cabinet Material:

Die- Catsing Aluminum / Iron

Viewing Angle:

H:160 V:140

Optimal Viewing Distance:

>=10m

Voltage:

DC5V

Brightness:

More Than 5000cd/㎡

Module Size:

320*160mm

Cabinet Size:

960*960mm

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

full color led signs outdoor

full color outdoor led display

Product Description

High Brightness Outdoor LED Advertising Screen P10 Building Mounted HD Billboard

High Brightness Outdoor LED Advertising Screen P6 P8 P10 Building Mounted Ad Billboard

Technical Parameters of P10 Advertising LED Screens

Parameter	Specification
Resolution/mm	10
Pixel configuration	1R1G1B
Pixel density/pixels/m²	10000m2
Module resolution	32*16
Module size/mm	320*160
View distance	10-300m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>5000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Driving mode	Constant driving current
Scanning mode	static dring
Frame rate	60Hz
Refresh frequency	3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	>72hours
Mean time Between Failure	>500hours
Life time	>100000hours
Environment temperature range	Operating temperature range -200c-500c
Maximum power :/m2	<800w
Average power:/m2	<300w
Self-check technology	LED spot self-check, communication check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault send out warning signs to the operators(need customization)
Software environment	Windows 1999, Windows
Input power cable	AC110v to 220v
Signal input	DVI
Warranty	2 years quality warranty, 10 years spare parts support

Features of P10 Module

The use of ultra-high brightness LED and high-quality plastic pieces
High-contrast hue can achieve a good display
Lightweight, easy to install, remove
Can be single-point, single lamp maintenance, low cost
Using a constant current way to drive LED, light uniformity, low power consumption
The pixel pitch is 6mm, a total of 32 * 16 pixels, each pixel consists of 1R1G1B

Advantages of P10 Advertising LED Screens

High brightness, ≥4000cd/㎡, is the only large display terminal that can be used all day in outdoors
Long life span, ≥ 100,000 hours
Large viewing angle. The Indoor angle of view is ≥ 160 degrees, the outdoor viewing angle is ≥ 120 degrees
An Intelligent control system, two kinds of systems, directly controlled by computer, or by WiFi
Compared with the LCD display, the LED display can be arbitrarily formed into a shape and seamlessly spliced

Advantages of Our Products

The product structure is resistant to 100 Km / h wind and 8 earthquakes
With excellent waterproof performance, safe and reliable power system
All components of the product can be processed according to customer requirements
All materials are environmentally friendly materials
The life of the product is more than 5 years
The warranty is for 2~5 years
We can provide additional installation, permanent technical supports, and training services

Control System

Certificates

Our Mission

To be the premier provider of creative, marketing and innovative solutions devoted to helping other companies succeed and grow.

Why Choose Us?

Packing & Shipping

Packing: wooden case, flight case for choose
Shipping: by air, sea, train, DHL, you are the boss

FAQ

1. How can I place an order?

Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /Whatsapp, in case of any delays.

2. What kind of display do we provide?

We have indoor/outdoor/mobile LED /rental LED display /LED stage/ Advertising LED display for you to choose. The customized service also could be provided.

3. What about the lead time for an order?

Always: 7-17 days after receiving your payment, as your order quantity, sometimes we have stock, can delivery within 7 days.

4. What about the warranty?

We have 2~5 years of quality guaranteed, spare parts such as the led module, receiving card, control card, power supply are damaged not cause of artificial damaged, then it's free maintenance and ship back new ones for replacement.

5. How about the quality?

Our LED products must be testing of at least 72hours before shipping, from purchase raw materials to ship, Each step has strict quality control systems to ensure LED display with good quality.

6. Can you offer technical support? Since it's my first time....

We provide free training for our customer, teach the client how to set up screens, make configuration of parameters, broadcast the videos through Nova star and colorlight or Linsn control systems, our engineer can directly teach you how to control, or help you to do if you are really don't know how to control(Our Engineer can text English, we can saving more time).
