Custom Big Flat Fixed p5 RGB Led Display Board Super Definition Thin Cabinet

Custom Big Flat Fixed p5 RGB Led Display Board Super Definition Thin Cabinet

  • Custom Big Flat Fixed p5  RGB Led Display Board Super Definition Thin Cabinet
  • Custom Big Flat Fixed p5  RGB Led Display Board Super Definition Thin Cabinet
Custom Big Flat Fixed p5  RGB Led Display Board Super Definition Thin Cabinet
Product Details:
Place of Origin: MADE IN CHINA
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SCXK-P5 outdoor
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: P5 Outdoor Smd Full Color Module Module Size: 160*160mm
Tube Chip Color: Full Color Pixel Pitch: 5mm
Module Qty: 1pcs Resolution: 32mm*32mm
Certificate: CE FCC SGS ROSH ISO9001
High Light:

led display rgb

,

rgb led screen



Custom Big Flat Fixed p5 RGB Led Display Board Super Definition Thin Cabinet


Since its establishment in 2005,Shenzhen Shichuangxinke Electronic Co.,Ltd is devoted to becoming a perfessional and innovative led display manufacturer,improving led display technology the world over.



our team has been innovating new ways to deliver the highest quality products, services and value to our customers, our led screens projects include some of the most advanced technology and forward-thinking design on the market today.



Our main focus has always been designing and manufacturing electronic outdoor/indoor led displays, led rental screens , portable led screens, outdoor Intelligence led screen and programmable display systems.



PRODUCT DESCRIPTION:





Tems Parameter
Pixel Pitch 5mm 6mm 8mm 10mm
Module Resolution(W*H) 32(W)*32(H) 32(W)*16(H) 32(W)*16(H) 30(W)*16(H)
Pixel Configuration 1R1G1B
Pixel Density 40000/ Pixel m2 27777 Pixel /m2 15625 Pixel /m2

10000/ Pixel

m2

Driving Method 1/8Scan 1/8 Scan 1/4 Scan 1/4 Scan
Refresh Frequency ≥60Hz
Driver IC Special constant current IC with high refresh rate & high grey scale
Grey Scale 16.7M(depending on the system and IC configuration)
Cabinet Size 320*160mm; 192*96mm; 320*160mm; 256*256mm
White balance Brightness ≥5000cd ≥6000cd ≥8000cd ≥7500cd
Color Temperature 8000K±500 (adjustable)
Viewing Angle Horizontal 140°Vetical 120°
Optimal Viewing Distance 5-30m 6-40m 8-45m 10-50m
Working Voltage AC 220V/110V ±10%
Module voltage DC4.2V
Max Power Consumption 780W/ m2 700W/ m2 650W/ m2 580W/ m2
Lifetime >1000hours
Operating Temperature –10 ~ 65



About our led displays


1.Wide application field & short ROI time:

commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media,shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen
air port LED display screen, telecommunication LED display screen system for information showing and instruction .

2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.


3. First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system


4. Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.





Methods for Quality Assurance
a. Aging
1. 100% fully test     Condition: 72 hours with 256 gray level


b. Vibration Testing
Condition: 3-5 min up and down in 5mm range


The epistar Led chip. with SMD and DIP Technology .

we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available




The wire or wireless controll system are available .( 3g and wifi controll will be welcome)



The steer consturction is very stable for led display,and you can purchase from your local market .



we can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.
we can choose the best shippment which is convenient to you!
SCXK group can give you the short delivery time and With the large production ability ,
you can feel free about this . By air ,by train, by sea?



Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.


Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6, Small order accepted.
