Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK- |
| Certification: | CE/ROHS/FCC/SGS/ul |
| Model Number: | P4.81 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in wooden case and flight case for outer packing |
| Delivery Time: | 10-15 working days after received your payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5,000/ Sq m per month |
| Product Name: | Rental P4.81 Led Screen | Cabinet Size: | 500*500 |
|---|---|---|---|
| Display Color: | Full Color | Led Chip: | Rgb Single Chip |
| Module Size: | 250*250 | Cabinet Material: | Die Casting Aluminum |
| Cabinet Resolution: | 104*104 | ||
| High Light: | led video screen rental,led rental screen |
||
SMD Led Full Color Screen , Lightweight Super Slim Rental Led Screen Energy Saving
Shenzhen SCXK Electronic co., LTD. was established in 2005, with modern management mode of the company's main production of indoor and outdoor full color module and the whole screen, indoor and outdoor full-color module and the whole screen, and series of peripheral products LED display sales, visual photoelectric is given priority to with foreign markets, 98% of all goods exported to foreign markets, the registered capital of two million RMB.
In today's market turmoil, our company takes the good faith management, customer first, want to customers think, do what customers do, to the company to grow rapidly, in just over a month to Belgium now is, outer Mongolia, Korea, Thailand, Singapore, India, South Africa, Malaysia, Brazil and other places of export goods.SCXK focus on specialization market - advertising and brand and entertainment, sports venues, large activities, provide forms for the LED application product solutions and high quality products.
| Parameter*Modules | Unit | Value |
| Pixel pitch | mm | 4.81mm |
| Pixel density | dots/sqm | 43264 |
| Pixels | Dots | 52x52 |
| Size | mm | 250x250 |
| Pixel type and configuration | 3 Chips in 1 SMD LED(2727) | |
| Brightness | nits(cd/sq.m) | >6000 |
| Drive type | 1/13 Scan | |
| Viewing angle-Horizontal | deg. | 130 (-65 ~ +65) |
| Viewing angle-Vertical | deg. | 130 (-65~ +65) |
| Red wavelength(dominant) | nm | 620-625 |
| Green wavelength(domi.) | nm | 520-525 |
| Blue wavelength(domi.) | nm | 470-475 |
| Lifetime(50% brightness) | Hours | 100,000 |
| Parameter*Cabinet | Unit | Value |
| Width | mm | 500mm |
| Height | mm | 500mm |
| Aspect ratio | 1:1 | |
| Diagonal | mm | 707 |
| Depth | mm | 75 |
| Area | sq.m | 0.25 |
| Weight | Kg | 9.5 |
| Pixels | dots | 104×104=10816 |
| Material | Aluminum | |
| Ingress protection | IP | IP65 |
| Operating temperature range | ℃ | -20 ~ +55 |
| Humidity operating | RH | 10% ~ 90% |
| Best viewing distance | m/feet | 5~ 13m /16~ 43’ |
| Input voltage(nominal) | V/AC | 110 /240 |
| Input power frequency | Hertz | 50/ 60 |
| Input power(max) | Watts | 200 |
| Input power(typical) | Watts | 80 |
| Cooling system | AIR |
| Parameter*Screen | Unit | Value |
| Colours | 1073.7 trillion | |
| Grey scale(linear) | Levels | 1024 levels per color |
| Brightness Control | Levels | 256 |
| Processing depth | bit | 14 ~ 16 |
| Video frame rate | Hertz | 30/60 |
| Display refresh rate | Hertz | 1200 ~ 2400 |
| Multimedia data format | MPG,AVI,WMV,RM etc. | |
| Data interconnection |
Cat 5E UTP /Optic Fiber |
The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available
The wire or wireless controll system are available .( 3g and wifi controll will be welcome)
Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.
Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6, Small order accepted.
Package
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
