SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen

SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen

  • SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen
  • SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen
SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen
Product Details:
Place of Origin: China
Brand Name: SCX
Certification: CE/ROHS/FCC/SGS
Model Number: SCX7.8125-H7.8125
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: 10 working days after received your payment
Delivery Time: 5,000/ Sqm per month
Payment Terms: T/T, Western Union
Contact Now
Detailed Product Description
Product Name: Transparent Poster Screen Type Size: 500mm*1000mm
Standard: CE/ROHS/FCC/ISO2001 Chip Color: 1R1G1B
Pixel Pitch: 7.8125mm Resolution: 64*128
Lamp: 2121 Kinglight Dot Density: 16384dots/sqm
High Light:

transparent led panel

,

transparent led display



SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen



Understanding that quality is the most important thing for both of us,there are 5 steps in total to guarantee good quality for you:


First is purchasing necessary original material strictly,these must be examined by engineers,
Second is go into producing,if tested have problem,then will rework right away,until the goods well,every worker is responsible just one part,this will be better for them to remember the details,because if one worker take too much work,then maybe he will forget something,only this,we can guarantee the quality,this is tested by QC,
Third is tested by general engineers,not only test one sample,it is must be every product,
Forth is examined by the third party,
Finally is by client.



LED Module Pixel Pitch V7.8125mm,H7.8125mm
LED Cabinet Cabinet Size 500mmX1000mm
Cabinet Resolution 64pixels *128pixels
Cabinets Material Die casting Aluminum Cabinet
LED Display Pixel Density 16384pixels/sq.m
Drive IC MBI5124
Power Supply G-energy
Brightness >1000cd/sqm
Display Color 16.7million
Viewing Angle 110°(Horizontal),50°(Vertical)
Best Viewing Distance 4m~150m
Refresh Rate 16bit ≥2880; 14bit ≥4800; 10bit ≥9600
Input Voltage AC220V/50H or AC110V/60H
Output Voltage DC5V 60A/80A
Grey Scale Levels 16bit
Installation Way Hanging / Stacking / Permanent Installation
Drive IC Taiwan MBI
Life-span 100,000 hours
Protection Level IP30
Failure percentage of leds less than 0.0003
Working Temperature -10~40°C
Drive Mode 1/3 scan constant current
Working Humidity 10%~90%
LED Encapsulation Self-development Side view LED lamp
Eliminate Ghost Line Yes
Working Voltage DC5V
weight <5.6kg
Control method Synchronization & Asynchronization
Control System Control System Linsn
Software LED Studio
Input Signal DVI/HDMI/DP
PC Operating system Microsoft Windows 7, 98, 2000, XP and Vist




SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen 0

SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen 1

SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen 2





Our Service



1)Training after order

After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment



2) Installation and debugging

BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.



3) Warranty

Warranty: 2 years warranty, lifetime maintenance

Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.



4) Maintenance

Maintenance principles: response in time, solve problems asap and ensure the use.

Maintenance period: In the maintenance period of the led display body, free of all maintenance charges

After maintenance period, only charge the material cost and labor cost.



Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.



Competitive Advantage:

1. 2 years’ warranty with free repair service

2. 24/7 Hours online Remote Support

3. Solution and PCB design

4. Free factory training

5. On site installation instruction and regular inspection

6, Small order accepted




SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen 3
SMD2121 kinglight Transparent LED Screen advertising / Transparent Poster Screen 4

1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.



♦ Why choose us:



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.







♦ FAQ



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.
