Rental Rental Die-Cast Aluminum Cabinet Suspended LED Display Light Aluminum Cabinet 3840HZ HD P1.56 1R1G1B

Brand Name:	SCX
Model Number:	SCX-P1.56
MOQ:	5sqm
Price:	4715USD/sqm
Payment Terms:	T/T, Western Union
Supply Ability:	5000sqm/month

Detail Information

Product Description

Detail Information

Place of Origin:

China(Mainland)

Certification:

CE,ISO,FCC,UL

Usage:

Indoor

Screen Dimension:

Customized Size

Tube Chip Color:

Full Color

Pixels:

1.56mm

Warranty:

3 Years

Module Size:

200*150mm

Brightness:

1000cd/m2

Life Span:

100000hours

Packaging Details:

Carton,wooden and flight cases.

Highlight:

led information display

full color led screen

Product Description

Hanging P1.56 LED Display Rental Light Weight Aluminum Cabinet 3840HZ HD

Indoor LED Display Screen Characteristic

1) Good illumination and no mosaic.

2) Can play different formats of image files, Flash, TV, video and video signals from other devices.

3) Different video frequencies can be changed freely at the same time, and the image can be enlarged or reduced.

4) High brightness and adjustable to meet various needs of customers.

5) Adopting real pixels instead of virtual pixels for better viewing effect.

Specifications:

SMD P1.56
Resolution/mm	1.56
Pixel configuration	1R1G1B
Pixel density/pixels/m²	410914dots/square meter
Module resolution	128x96
Module size/mm	200x150mm
View distance	2-30m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	1000cd/square meter
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/32 SCANNING
Frame rate	60Hz
Refresh frequency	3840Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted
	255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Self-check technology	LED spot self-check, communications check, power check,
	temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault,
	send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Rental Rental Die-Cast Aluminum Cabinet Suspended LED Display Light Aluminum Cabinet 3840HZ HD P1.56 1R1G1B 0

Our service:

1) Reply your inquiry in 24 working hours.

2) Experienced staffs answer all your query in fluent English,Spanish,French,German etc

3) Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.

4) Special discount and protection of sales area provided to our distributor.

5) Warranty: Two Years, a little investment for longer warranty time.
