| Place of Origin: | China(Mainland) |
| Brand Name: | SCX |
| Certification: | CE,ISO,FCC,UL |
| Model Number: | SCX-P1.56 |
| Minimum Order Quantity: | 5sqm |
|---|---|
| Price: | 4715USD/sqm |
| Packaging Details: | Carton,wooden and flight cases. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm/month |
| Usage: | Indoor | Screen Dimension: | Customized Size |
|---|---|---|---|
| Tube Chip Color: | Full Color | Pixels: | 1.56mm |
| Warranty: | 3 Years | Module Size: | 200*150mm |
| Brightness: | 1000cd/m2 | Life Span: | 100000hours |
| Highlight: | led information display,full color led screen |
||
Hanging P1.56 LED Display Rental Light Weight Aluminum Cabinet 3840HZ HD
1) Good illumination and no mosaic.
2) Can play different formats of image files, Flash, TV, video and video signals from other devices.
3) Different video frequencies can be changed freely at the same time, and the image can be enlarged or reduced.
4) High brightness and adjustable to meet various needs of customers.
5) Adopting real pixels instead of virtual pixels for better viewing effect.
Specifications:
| SMD P1.56 | |||||
| Resolution/mm | 1.56 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 410914dots/square meter | ||||
| Module resolution | 128x96 | ||||
| Module size/mm | 200x150mm | ||||
| View distance | 2-30m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | 1000cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/32 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | 3840Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
