High brightness 1r1g1b transparent led panel screen with 15.63mm pixel pitch

Product Details:

Place of Origin:	China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/SGS
Model Number:	TL15.63

Payment & Shipping Terms:

Minimum Order Quantity:	negotiation
Price:	negotiation
Packaging Details:	Packed in wooden case and flight case for outer packing
Delivery Time:	10 working days after received your payment
Payment Terms:	T/T or western Union
Supply Ability:	5,000/ Sq m per month

Contact Now

Detailed Product Description

Product Name:	Transparent Led Screen	Cabinet Size(W * H):	1000mm1000mm80mm
Standard:	CE/ROHS/FCC/ISO9001	Tube Chip Color:	1r1g1b
Pixel Pitch:	15.63mm	Module Qty:	1pcs
Resolution(W*H):	64dots*64dots
High Light:	transparent led panel , transparent led display

High brightness 1r1g1b transparent led panel screen with 15.63mm pixel pitch

Shenzhen Shichuangxinke Electronic Co.,Ltd is specialized to the LED lighting products, including indoor and outdoor applications. We are high-tech company, with product developing and manufacturing , project services , market development
And with the domestic design companies and engineering companies, continue to offer high-quality goods project. We have advanced production equipment and inspection instruments,strict quality standard and efficient management methid . After years of efforts , our product is become to high-end LED products ,they are adapt to the market launch, and reliable application .and reliable application;approved by CE,CCC,ROHS,FC and so on certification.

High transparency:92% on transparency makes the led bulbs almost invisible above a specific distance on screen.
Flexible installation:methods for various projects.
Light-weighted: perfectly applied for mobile shows and rental applications.
Simple installation: directly installed behind the glass. So there is no need for any changing on building structure, very suitable for glass building advertising and decoration.
High light transmittance: lights on the stage can easily get through screens

92% high transparent led screen, TL15.63 full color screen with cabinet size 1000*1000mm
LED Module	Pixel Pitch	15.63mm
LED Cabinet	Cabinet Size	1000mmX1000mm*80mm
	Cabinet Resolution	64pixels *64pixels
	Cabinets Material	Die casting Aluminum Cabinet
LED Display	Pixel Density	4096pixels/sq.m
	Drive IC	MBI5024
	Power Supply	Series connection
	Brightness	>6300cd/sqm
	Display Color	16.7million
	Viewing Angle	110°(Horizontal),50°(Vertical)
	Best Viewing Distance	5m~150m
	Max Power Consumption	650w/sqm
	Average Power Consumption	260 w/sq.m
	Refresh Rate	16bit≥4800,14bit≥9600,10bit＞10000
	Input Voltage	AC220V/50H or AC110V/60H
	Output Voltage	DC5V 60A/80A
	Grey Scale Levels	16bit
	Installation Way	Hanging / Stacking / Permanent Installation
	Drive IC	Taiwan MBI/Domestic High refresh rate IC(Optional)
	Life-span	100,000 hours
	Protection Level	IP30
	Failure percentage of leds	less than 0.0003
	Working Temperature	-10～40°C
	Drive Mode	Static
	Working Humidity	10%~90%
	LED Encapsulation	Self-development Side view LED lamp
	Eliminate Ghost Line	Yes
	Working Voltage	DC5V
	weight	<9.6kg
	Control method	Synchronization & Asynchronization
Control System	Control System	Mooncell/ Nova/ Linsn(Optional)
	Software	LED Studio
	Input Signal	DVI/HDMI/DP
	PC Operating system	Microsoft Windows 7, 98, 2000, XP and Vist

High brightness 1r1g1b transparent led panel screen with 15.63mm pixel pitch 0

High brightness 1r1g1b transparent led panel screen with 15.63mm pixel pitch 3

Methods for Quality Assurance

a. Aging testing :100% fully test Condition: 72 hours with 256 gray level
b. Vibration Testing:Condition: 3-5 min up and down in 5mm range

Advantage

1. OEM service,No MOQ
2. Easy installation,regular items in Stocks
3. Offering free design drawing as requested.
4. Remote controlling and adjusting are available.
5. Wooden case or flight case,you are the boss.
6. Your reply will be replied within 24 hours.
7. Fast delivery: Usually 6-8 working days
8. Excellent R&D team,factory Price and assure you quality goods.

Payment and delivery

1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.

♦ Why choose us:

Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.

Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.

Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.

♦ FAQ

What kind of payment terms you can accept ?
We can accept T/T and Western Union.

What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.

What is your delivery time ?
Within 7-35 days according to your area and quantity.

Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
