Home Products Indoor Full Color LED Display

P1.5 Indoor Led Advertising Wide Viewing Angle

Product Details:

Place of Origin:	shenzhen,China
Brand Name:	SCX
Certification:	CE,CB,IEICC,FC
Model Number:	indoor p1.5

Payment & Shipping Terms:

Minimum Order Quantity:	6sqm
Price:	negotiation
Packaging Details:	wooden case，flight case
Delivery Time:	5-7 working days
Payment Terms:	T/T, Western Union
Supply Ability:	3200 sqm per sqm

Contact Now

Detailed Product Description

Brightness:	1000-1200nits	Color Temperature:	6500K
Control System:	Synchronization	Display Type:	Indoor Full Color LED Display
Gray Scale:	16bit	Refresh Rate:	1920Hz
Viewing Angle:	140°/140°
High Light:	wide viewing angle indoor led advertising , 1.5mm indoor led advertising , advertising led display p1 5

full color led display panel indoor fixed 4k video wall p1.5 led screen

Mini-Pro LED Display

Application Scope: Led small spacing display screen is widely used in radio and television, road traffic command center, public security monitoring, power system, military, water conservancy, urban management and so on Main Features: Low brightness, high gray, light and thin, fashionable, ultra wide viewing angle and fast maintenance.

00:08

00:28

Products Description

MODEL	KW63L09	KW63L11	KW63L12	KW63L15	KW63L18
Pixel Pitch(mm)	0.9375mm	1.17mm	1.25mm	1.5625mm	1.875mm
Pixel Density(pixels/sqm)	1,137,778	728,128	640,000	409,600	284,444
Cabinet Resolution	640*360	512*288	480*270	384*216	320*180
Lamp Type	MINI Four in one	SMD0808	SMD1010	SMD1010/1212	SMD1515
Brightness	＞500 nit	＞600 nit			＞1000 nit
Cabinet Size(mm)	600337.538mm
Pixels Calibration	Standard color and brightness calibration
Gray Scale	14~16Bit
Color Temp	2000K~10000K
Control System	Synchronous Control
Frame Frequency	50/60Hz, 120Hz
Refresh Rate	3840Hz
Working Voltage	AC:100V~240V, 50~60Hz
Power Consumption	Max: 700w/㎡ Ave: 200~250w/㎡
Lifetime(hours)	100,000
Operating Temp(℃)	-10℃~+60℃
Storage Temp(℃)	-25℃~+60℃
Humidity Range	10%~80%, Non-condensing
Weight	6.0kg/Cabinet

Easy Front Sevice Design

Cabinet and modules are separatedly packed, first install cabinets and then install modules.
Cabinets and modules are wireless connected;
Smart adjust: unique alignment features ensure the video wall is perfectly aligned and seamless, the flatness tolerance of screen is ≤0.1mm.

Intelligent Low Power Consumption Design

It can be optional with common-cathode or common-anode, Intelligent data storage function can be customized.

Low Brightness

With High Gray Scale

It use high quality LED Lamps and PWM drive IC, goes with Kewei patented mask and special image arithmetic processing that makes a better color rendering, color revivification and better details with excellent gray scale in low brightness mode(100cd/㎡).

TOPCOB

Unique Design Patent

It own unique LED surface treatment technology, can achieve high level of anti-collision, anti-water, anti-dust, protecting screen effectively, work properly in corrosive, damp and mist evironments.

HDR High Dynamic &

High Refresh Rate Display

System date polishing process and HDR high dynamic fine imaging can function at low brightness and high gray scale simultaneously, which enhances the level of gray scale, makes scene more real and makes color more corgeous. With anti-gamma corrction technology. Dynamic expression of color redition and 3840Hz high refresh rate is pratical and enjoyable.
