P4 Indoor Aluminum Panel HD Waterproof SMD LED Screen Billboard 1R1G1B Rental led video wall screen

P4 Indoor Aluminum Panel HD Waterproof SMD LED Screen Billboard 1R1G1B Rental led video wall screen

Brand Name: Shichuangxinke
Model Number: SCXK-P4
MOQ: 3 square meters
Price: USD1900-2100 per square meters
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000sqm per month
Detail Information
Place of Origin:
China ,Guang Dong
Certification:
CE RoHS FCC CCC TUV UL
Resolution/mm:
4
Pixel Configuration:
1R1G1B
Scanning Mode:
1/8 Scanning
Module Size:
256x128MM
Cabinet Size:
512x512MM
Material:
Aluminum
Certificates:
CE RoHS FCC CCC UL
Application:
Stadium,airport,shopping Mall,street Advertising
Warranty:
3-5 Years
Packaging Details:
wooden box flight case, wooden case, carton, it is up to you.
Highlight:

Waterproof SMD LED Screen Billboard

,

1R1G1B Rental LED Screen Billboard

,

P4 Indoor Aluminum Panel LED Screen

Product Description







P4 Interiror Aluminum HD waterproof SMD LED Screen billboard 1R1G1B For rental





1. CNC+ die-casting process cabinet

The CNC+ die-casting process greatly improves the flatness of the LED screen surface (accuracy can reach 0.05mm), ensuring seamless and accurate installation of the full screen.

2. Ultra-thin
The thickness is 60mm, saving installation space and packaging size, ensuring fast movement and installation.

3. Light weight
The full screen weighs only 10KG, one person can easily hang it, and two people only need 30 minutes to complete the installation of a 12 square meter LED screen, saving time and labor costs.

4. Easy and fast installation
We have adopted a plug-and-play design for this series, and the input and output operations of the power and signal connectors are very convenient and fast; the signal connection can be horizontal and vertical, meeting rental applications in any situation.





Specifications :



Outdoor P4 LED advertising Display Screen
Information Pixel Pitch 4mm
Pixel Density 62500 Pixels/m2
Pixel Configuration 1R1G1B
LED Wavelength Red: 615 nm - 635 nm
Green: 520 nm - 535 nm
Blue: 465 nm - 475 nm
LED Module Module Size(mm) 256(Width) × 128 (Height)
Module Resolution 64(Width) × 32 (Height)
Cabinet Cabinet Size(mm) 512 (Width) ×512(Height)
Cabinet Resolution 128 (Width) × 128 (Height)
Total QYT Module Per Cabinet 4 (Width) ×4(Height)
Cabinet Weight 30kg/m2
Cabinet Material Die-casting Aluminum LED Display
Power Input Voltage 100-240V AC, 50/60Hz
Max Power Consumption 1200 Watt/m2
Avg. Power Consumption 720 Watt/m2
  Brightness ≥1800cd/m2
Brightness Uniformity Luminance Discrepancy < 5%
Best Viewing Angle Horizontal:140°,Vertical:70°
Viewing Distance 5 - 15 meters
Ambint Conditions Temperature Range Working:-20deg. to +60deg
Operating Humidity 10%90%RH
Ingression Protection Grade IP40
Processing Scanning Mode 1/8 scanning
Signal Input DVI, Composite Video for Live Video
Supported Networking Through LAN/WAN, RS 232/RS485
Controller Linsn or Nova






Competitive advantages:

1. P4 SMD outdoor full-color LED display screen has uniform brightness and color;
2. P4 full-color LED screen uses all-black LED chips;
3. Indoor full-color LED video screen has a contrast ratio of up to 1000:1, reflecting the true color of the content;
4. Adopts Sum driver IC, high refresh rate, high grayscale level;
5. Horizontal and vertical 140-degree ultra-large viewing angle;
6. P4 LED display screen has high resolution, suitable for indoor rental activities with high requirements for presentation quality, and its cost is lower than that of large indoor LED display screens;



P4 Indoor Aluminum Panel HD Waterproof SMD LED Screen Billboard 1R1G1B Rental led video wall screen 0







Our Company:

P4 Indoor Aluminum Panel HD Waterproof SMD LED Screen Billboard 1R1G1B Rental led video wall screen 1

P4 Indoor Aluminum Panel HD Waterproof SMD LED Screen Billboard 1R1G1B Rental led video wall screen 2







FAQ:

1.Q:Are you a factory or trading company?

A:We are a factory,located in Dalang,Longhua District .



2.Q:What kind of payment terms you accept?

A:We accept T/T,Western Union,MoneyGram etc.



3.Q:What's packaging?

A:1.Flight case packaging

2.Wooden case packaging

3.36pcs in one case packaging

4.Customized packaging



4.Q:Does you have CE/ROHS certificates?

A:Yes, we offer the CE & ROHS certificates .



5.Q:What's the shipping method,shipping time?

A:Our products could be shipped by Sea, by Air, and by Express.

by sea:20-40days; by air:5-10days ;by express:3-6days



Welcome to visit our website and inquire us more info,waiting for you all the time!!!
