Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P5 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD 2400-2700 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 5 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 16 Scanning | Module Size: | 2.71X1.35MM |
| Cabinet Size: | 2710x1350mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Night Club,Bar Club | Material: | Aluminum |
| Warranty: | 3years | ||
| Highlight: | led full color screen,indoor led billboard |
||
Bar Club DJ booth LED Display constant current scanning P5 LED Display
Description:
LED DJ booths Display
Creative LED Displays DJ Booth
LED Diamond DJ Booth Screen
creative dj booth display for night club
DJ Booth Facade
Six Faces LED Cube Display
LED Cube Display Applications:
High Resolution Indoor HD Video LED Wall for LED Bar,Shopping Center and Big Concert.
Trading Terms:
DELIVERY TIME: Within 3 working days after receipt of payment: payment method: paypal/western union or 100% wire transfer before shipment. Packing: sturdy cardboard box. Warranty: 2 years warranty. Shipping Method: Ship Outdoor LED Modules via DHL, UPS, Fedex and EMS: Shipping Cost: After you tell us the quantity and shipping address, we will calculate the best shipping cost for you.
Specifications :
| Indoor Creative LED Cube Display | |||||
| Pixel Pitch | 5mm | ||||
| Pixel configuration | RGB | ||||
| Pixel density/pixels/m² | 65410/m² | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 2.71x1.35mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/8 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Shipping details:
UPS/Fedex/TNT/DHL, Air Freight, Sea Freight
Q:1, How to arrange payment?
Our payment method is usually T/T, for samples and small orders, we also accept Western Union, Paypal or MoneyGram.
Q:2, How long is our warranty?
We provide 5 years to 1 year warranty for different types of LED screens, usually we will prepare extra LED screen modules for each screen as spare modules. If some modules fail, you can use our spare modules for replacement. When all spare modules are used up, you can send the modules back to us for repair. We will send the modules back to you after repair, testing and aging. We will send the modules back to you after repair, testing and aging.
Q:3, How to become our distributor?
After becoming our distributor, we can share the annual profit with you, and we can also send engineers or sales staff to your company to support your business. For the after-sales service of LED screens, we will cooperate with you throughout the life cycle of LED screens.
Q4: How to maintain my LED screen?
LED screens are usually maintained once a year, which includes removing the LED mask, checking the cable connections, and if any LED screen module fails, you can replace it with our spare modules.
FAQ
Q1: What can you buy from us?
A: Rental LED Display, Outdoor LED Display, Indoor LED Display, Transparent LED Screen, Floor Tile Screen, Creative Design LED Screen and Etc.
Q2: Can I customize it?
A: Of course. All the goods can be customized, we have a professional product development team, welcome to customize.
Q3: What is Price per square meter of screen?
A: Welcome to send us inquiry. Our professional sales engineers will provide suitable solutions.
Q4: What is the warranty?
A: 5-8 years Warranty.
Q5: How many days for producing?
A: 1-3 days for inventory products and 10-15 days for customized products.
Q6: How to operate and use it?
A: It can by controlled by PC and Smartphone very easily.
Welcome to inquiry for more information. We provide video guidance and remote assistance.
