P3.91/P4.81/P5.95 Outdoor or Indoor Rental Die-casting Aluminum Cabinet.
Cabinet size:500 x 500mm or 500 x 1000mm
1.Thin and light design,one person can handle the installation;
2. 500*500/500*1000mm big panel, speedily and easily mounting, perfect 16:9 colorful image;
3.Ultra thin body, Die-casting aluminum structure, high-accuracy connection, error<0.1mm;
4.Natural aluminum heat conduction design (no-cooling fan),quiet world.
5. Application in concert, exhibition, wedding, conference, meeting, annual party, DJ bar and other events.
1. Multifunctional:
The screen could be hung up for different kinds of event. And it also could be put on the floor as dance floor.
2. Curved design is available:
The screen could be both curved design and regular straight design.
3. Cabinet edge protection design:
The bottom modules on the cabinet are about 5mm off the round. So they will not be hit when we put the cabinets on the ground. This feature greatly protects the LEDs during assembly and disassembly.
4. Ladder function:
The cabinet is with strong rack, which could be used as a ladder to climb up for maintenance.
5. Quick and more secure assembly:
Only 2 steps to lock the cabinets together. And the lock is with Anti-release design which makes it more secure.
Specifications :
| outdoor SMD P3.9 |
| Resolution/mm |
5 |
| Pixel configuration |
1R1G1B |
| Pixel density/pixels/m² |
65536/m² |
| Module resolution |
64x64 |
| Module size/mm |
250x250mm |
| View distance |
14-300m |
| Single point brightness adjust |
Can be added |
| Single point color adjust |
Can be added |
| White balance brightness |
5000cd/㎡ |
| Color temperature |
6500K-9500K |
| Horizontal view angle |
120(degrees) |
| Vertical view angle |
60(degrees) |
| Signal Process bit |
10 or 16bit |
| Grey process |
1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances |
Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode |
Constant driving current |
| Scanning mode |
1/7 SCANNING |
| Frame rate |
60Hz |
| Refresh frequency |
3840Hz |
| Control mode |
Computer synchronous |
| Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point |
<1/10000 |
| Working hours |
≥72hours |
| Mean Time Between Failure |
>5000hours |
| Life time |
100000hours |
| Life-all-white(brightness halving) |
50000hours |
| Environment temperature range |
Operating temperature range: -20-45℃ |
| Self-check technology |
LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring |
Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment |
WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres |
Deviation<3% |
| Brightness uniformity |
<10% |
| Color uniformity(chromaticity coordinate) |
±0.003 |
| Power supply request |
AC85-264V(50Hz-60Hz) |
| Contrast |
(1000:1) |
| System protection |
Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) |
working:10-95% |
| Humidity(storing) |
storing:10-95% |
Our Services:
1)Reply your inquiry in 24 working hours.
2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
5)Special discount and protection of sales area provided to our distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty time.
FAQ
Q1:How to choose a proper led screen for your need?
A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?
Q2:Which pixel pitch should i choose?
A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).
Q3:Which control system should i choose?
A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
Q4:How to order from your compamy?
A:You can both place order to us by alibaba online or to our company directly offline, before place order welcome to contact us for confirmation.
Q5:How to pay?
A:We accept payment online through alibaba, or offline to our company account by T/T bank, or paypal or western union.
Q6:How to ship?
A:It is optional and we respect customer's choice. You can choose to ship by air cargo, by DHL(Fedex,UPS etc) internation express company, or by sea according to your goods weight and volume and the delivery time you need.
Q7:How to install it after i received it?
A:We will offer you the drawing to guide you for installation, we could also offer steel drawing, software set up drawing or photo or send our engineer fly to you for help if needed.
