HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard

HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard

  • HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard
  • HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard
  • HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard
  • HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard
HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard
Product Details:
Place of Origin: Shenzhen
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P4
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7 working days after receive your payment
Supply Ability: 3000sqm per month
Contact Now
Detailed Product Description
Module Size: 256mm*128mm Pixel Pitch: 4mm
Color Temperature: 6500K-9500K Scann Mode: 1/16 Scanning
Opitmal Viewing Distance: ≥3m Cabinet Size(WXH): 512x512mm
Cabinet Resolution: 128dots X128dots Pixel Density: 62500 Dots/m2
Brightness: ≥1300cd/㎡ Number Of Colors: 16.7 Trillion
Brightness Adjustment: 0-100% 8 Levels
Highlight:

1300cd/㎡ LED Advertising Billboard

,

SMD2121 LED Advertising Billboard

,

1R1G1B Indoor Led Display Signs

SMD Full Color Indoor P2 P3 P4 Super Market Video Wall Slim 4mm Advertising Digital Billboard LED Display





Indoor Full Color Led Display Features



1. Ultra-thin magnesium alloy is easy to shape, and can be used to make high-end, thin products, making the cabinet thinner

2. Good vibration absorption For example, at a stress level of 35MPa, the attenuation coefficient of magnesium alloy AZ91D is 25%, while that of aluminum alloy is only 1%. At a stress level of 100MPa, the attenuation coefficients of magnesium alloys AZ91D, AM60, and AS41 are 53%, 72%, and 70%, respectively, while that of aluminum alloy A380 is only 4%. Magnesium alloy has a good noise reduction effect.

3. Dimensional stability Temperature and time changes have little effect on the instability of magnesium alloy die-casting products, and the precision is higher after CNC processing.

4. Good heat dissipation Fast cooling speed - good heat dissipation performance, protection module circuit







 Indoor Full Color Led Display Specifications



Type SMD2121
Composition 1R1G1B
Scan method 32S
Resolution 64x 32dots (W x H)
Pixel pitch 4mm
Module size 256 x 128 mm
Module quantity 2x4
Resolution 128 x 128(W x H)
Cabinet size 512 x 512mm
Panel Type and Material Die-casting aluminum
Best viewing distance 4-47m
Maximum power <1000W /m2
Viewing angle 160°/160°
Brightness 1000cd/m2
Pixel density 62500dot/m2
Control system Synchronous System
Lifespan 100,000 hours
Frame frequency 60Hz
Installation Hanging/Fixed with support bracket
Certification CE, ROSH,FCC,CB,IECEE,SASO




Full Color Indoor Led Display Installation Method

 HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard 0

HD No-Smear Flexible P2 P3 P4 1R1G1B SMD2121 1300cd/㎡ LED Billboard 1







Our Service



pre-sales

In order to build long term business relationship with you,Here belowing are what we will do for you :

1, Pictures and videos related to your peoject will be offered for your reference

2. Engineering cases will be shared with you

3. Related drawing share with you

4, Best led display cost and shipping cost offered for you

5. Check with previous customers that in your place about installation fee for you



After-Sales

1. 3 years warranty , Lifetime free maintenance.

2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

3. Customer satisfaction tracking report.

4. Free technician training.

5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on

6. Special service for big project, such as stadium, exhibitions, squares and so on.







 Why choose us



1. High quality:100% tested before shipping, Best quality LED chip tube the CREE,



SILAN, OPTO, EPISTAR assuring high brightness and long life span. industry-leading



2. Strong productivity:5000 pieces per month, Shorter delivery time



3. Light weight:aluminum cabinet greatly saving fright cost and conveniently installing.


4. Stable performance:our most basic guarantee:the aging time exceeding 24 hours. Malfunction
dot rate less than 0.0001. MTBF more than 10000 hours.



5. Supporting different formats of images and videos:Flash, WAV/MIDI, Videos from TV and other equipments.
