Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | SHENZHEN |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL/CB/IECEE/SABER |
| Model Number: | P10 |
| Minimum Order Quantity: | 1 Square Meter/Square Meters |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7working days after receive your payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000sqm per month |
| Tube Chip Color: | FULL COLOR | High Brightness: | 7000 |
|---|---|---|---|
| Pixel Conformation: | 1R1G1B | Operating Voltage: | 220±10% Or 110±10% |
| Moduel Size: | 160×160mm | Interface: | HUB75B |
| Drive Type: | 1/16 Scan | Power Consumption: | Max: 800W/m², Avg: 400W/m² |
| Cabinet Weight: | 35kg/panel | Ip Grade: | IP65 |
| Warranty Time: | At 2 Years | Brightness Control: | 256grade |
| Smd Or Dip: | SMD | Pixel: | 10mm |
| Dot Density: | 43222dots/sqm |
1. High brightness: it can still display clearly even under direct sunlight, suitable for outdoor environment.
2. High resolution: pixel pitch is 10mm, providing high image and video resolution and clear content display.
3. Wide Viewing Angle: Wide viewing angle increases audience coverage.
4. Energy saving and environmental protection: low energy consumption and long life, saving energy and maintenance costs.
5. High refresh rate: smooth video playback and dynamic display, avoiding image dragging and flickering phenomenon.
6. Multi-functional application: Support multiple signal inputs.
7. High stability: waterproof, dustproof and shockproof performance.
8. Convenient maintenance: easy and quick installation and maintenance, reducing the difficulty and cost of maintenance.
Specification:
| Part No. | P10 |
| Driving Mode | Static Full Color |
| Brightness | 10000cd |
| Contrast | ≥3000:1 |
| Display Color | 1.07 billion |
| View Angle | 120° degree Horizontal & 60° degree Vertical110 |
| Brightness Adjustment | 0-100% 8 levels |
| Operation Power | 220V 60HZ |
| Max Power Consumption | 750 w |
| Average Power Consumption | 280 w |
| Frame Update Frequency | 100hz |
| Screen Refresh Frequency | 480hz |
| Gamma Correction | (-0.5—5.0) |
| Operating Temp. | - 10° —+55° Celcius degree |
| Operating Humidity | 10 - 90 % RH |
| Operating Life | 100,000 Hours |
| MTBF | 5000 Hours |
| Protection Level | IP65 |
| Out of Control Pixel Rate | 0.01% |
| Input Signal Support | Composite, S-Video,Component,VGA, DVI,HDMI,SDI,HD_SDI |
| Control Distance | UTP CAT5E:100m; Multi-mode Fiber:500m;Single-mode Fiber:10km |
| Support VGA Mode | 800 x 600, 1024 x 768, 1280 x 1024, 1600 x 1200, |
| Brightness Correction | Dot by Dot,module by module, cabinet by cabinet |
| Control Mode | Synchronous display with control PC by DV |
