Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P10 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD +550-750 +square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 10 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/4 Scanning | Module Size: | 160x160MM |
| Cabinet Size: | 960x960MM | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 3-5 Years | ||
| Highlight: | P10 Outdoor Advertising LED Screen Module,Electric Outdoor Advertising LED Screen Module |
||
easy maintain high quality outdoor advertising led screen module p10
We are a professional LED display screen manufacturer and supplier in China. Our primary products include indoor LED display screen, outdoor LED display screen, indoor rental LED screen, stadium LED display screen, LED curtain, LED ceiling light, and LED panel light.
P4 LED Display Screen P5 LED Display Screen P6 LED Display Screen P7 LED Display Screen P8 LED Display Screen P10 LED Display Screen
Other Products:
Indoor rental LED screens are rich in color. Color and brightness are highly consistent across the entire screen. With high contrast ratio and high refresh rate, images are rendered well on the LED screen without any delay.
Rental LED Screens Traditional motorized screens, such as CRT TV walls, rear-projection TV walls, front-projection screens, and plasma display panels (PDPs), have limited applications due to insufficient brightness, size limitations, and installation difficulties.
For outdoor stadium video screens, we use visual pixel technology to achieve more realistic video display effects. For indoor sports video screens, we utilize SMD triplex technology, which provides a wider viewing angle, higher refresh rate and higher brightness.
The LED drapery mechanism is designed to allow for the efficient installation and removal required for rental and staging applications. The most important feature of this product is its high transparency, which can bring different visual effects to the audience by changing the brightness.
Specifications :
| outdoor DIP P10 | |||||
| Resolution/mm | 10 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 10000/m² | ||||
| Module resolution | 32x16 | ||||
| Module size/mm | 160X160MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Applications:
On roof of building LED Billboard
Mounted on building LED Billboard
Put on steel pole LED Billboard
Cross bridge information LED Billboard
Shopping Mall LED Billboard
Commercial Advertising LED Billboard
Church LED Billboard
Road Show LED Billboards
High Speed Way LED Advertising Billboard
