Place of Origin: | China ,Guang Dong |
Brand Name: | Shichuangxinke |
Certification: | CE RoHS FCC CCC TUV UL |
Model Number: | SCXK-P1.667 |
Minimum Order Quantity: | 1 square meters |
---|---|
Price: | negotiation |
Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
Delivery Time: | 7-10 working days after deposit payment received |
Payment Terms: | L/C, T/T, Western Union, D/P, D/A |
Supply Ability: | 5000sqm per month |
Resolution/mm: | 1.667 | Pixel Configuration: | 1R1G1B |
---|---|---|---|
Scanning Mode: | 1/30 Scanning | Module Size: | 200x150MM |
Cabinet Size: | 400x300MM | Certificates: | CE RoHS FCC CCC UL |
Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum/iron |
Warranty: | 3-5 Years | IC: | MB5124/MB5024 |
Highlight: | Full Color Indoor LED Display,Small Pitch Indoor LED Display,Indoor LED Display P1.667 |
P1.667 indoor full color HD easy maintenance LED screen for stage and concert
why choose us
1. High brightness is adjustable to meet customers' changing needs in different environments.
2. High refresh rate and high grayscale: realistic images meet the high visual quality requirements for commercial use
3. Adopting the latest LED technology and control technology, the resolution is higher, the colors are brighter, and the electronic components are fewer, which reduces the failure rate.
Features of led display:
1. Use high-quality LED chips with strong anti-static ability.
2. Wide viewing angle, smooth display, good visual effects at all angles.
3. Lamp beads are integrated with driver IC, multi-circuit structure, uniform current distribution, low power consumption, and fast heat dissipation.
4. Ultra-high brightness, low attenuation, high reliability, and good weather resistance.
5. High contrast. Using black lamp beads, the contrast can be increased by 50%.
6. High refresh rate, high grayscale, ghosting elimination, low power consumption, low EMI, leakage prevention, support for multi-channel redundant backup, and point-by-point correction.
Specifications :
outdoor DIP P1.667 | |||||
Resolution/mm | 1.667 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 360000/m² | ||||
Module resolution | 120x90 | ||||
Module size/mm | 200x150MM | ||||
View distance | 14-300m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | >7500cd/㎡ | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/30 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | >3000Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
1. How long could i receive the inquiry reply ?
A: You will get a reply within 24 hours.
2.How long do you provide warranty time ?
A: Different product offer different time frame warranty, but all product here we offer 2 year at least warranty
3.How long will it take to deliver goods ?
A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment.
4.What about your pre-sale service and post-sale service?
A: For pre-sale service: We have a professional sales team and a 12 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.
Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!
5. How can you ensure the led display product quality?
A: Our led display screen quality is our core competence, for 7 years, what we rely on.We have each stardard process to make quality products.
If any quality failures within warranty time, we will refund you on alibaba.
More products
P5 outdoor led module P8 outdoor led module P8 outdoor led cabinet
P3.91 indoor led module P3.91 indoor led cabinet
FAQ
Q1: How to help client choose suitable display?
A1:
(1)specific application scenario
(2)viewing distance requirement
(3)display brightness requirement
(4)specific installation environment
(5)budget and cost control
Q2: What about your technical support?
A2: Proffessional engineers are on standby, can offer guidance, on site technical support as required.
Q3: What's the control system?
A3: For synchronization control: Nova, Linsn or Mooncell control system.
For asynchronous control: Onbon or Xixun control system.
Q4: What's the warranty of your LED displays?
A4: We provide 2 years warranty and conditioned lifetime technical support for our LED display products.
Q5: What's your payment method?
A5: Our payment method is T/T 30% as deposit, balancing before delivery.
