Name: P10 SMD Outdoor Waterproof Full Color LED Display for Stadiums
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P10
Price: 10000.00 USD
Availability: InStock

Home Products Stadium LED Display

P10 SMD Outdoor Waterproof Full Color LED Display for Stadiums

Product Details:

Place of Origin:	Shenzhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB
Model Number:	P10

Payment & Shipping Terms:

Minimum Order Quantity:	6 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T,Western Union,MoneyGram,D/P,D/A,L/C
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixel Pitch:	10mm	Tube Chip Color:	Full Color
Led Type:	SMD 3535	Display Function:	Video/Text/Image
Waterproof:	IP65	Frame Frequency:	>=60HZ
Dot Density:	10000	Brightness:	>=5000cd/m2
Highlight:	Outdoor Football Stadium LED Display Screen , SMD Football Stadium LED Display Screen

Outdoor Waterproof Full Color P10 SMD Football Stadium Perimeter LED Display Screen

Key Specifications

Attribute	Value
Pixel Pitch	10mm
Tube Chip Color	Full color
Led Type	SMD 3535
Display Function	Video/Text/Image
Waterproof	IP65
Frame Frequency	≥60HZ
Dot Density	10000
Brightness	≥5000cd/m²

Detailed Specifications

Pitch size: 10mm

Module size: 320mm × 160mm

Panel pixel: 32 × 16 dots

Pixel configuration: 1Red/1Green/1Blue

Color scale: 256-65536grade/16777216colors

View angle: 160°(H)/120°(V)

View distance: ≥10m

Power consumption: 100-1200W/m²

Net weight: 28.5kg/pcs

Operating temperature: -25°C to +60°C

Operating humidity: 10%-95%RH

Life time: ≥100,000 hours

Product Features

High refresh rate (up to 3800Hz): No flicker during live switch, ensuring high-definition display quality even under professional camera conditions.
