Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P10 |
| Minimum Order Quantity: | 1-1000sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T |
| Supply Ability: | 5000sqm |
| Pixel Density: | 10000 | Brightness: | 6000 |
|---|---|---|---|
| Control System: | Nova | LED Shape & Size: | 3mm Smd3535 |
| Module Size: | 320*160 | Driver Mode: | 1/4 |
| Operation Power: | 220V 60HZ | Display Color: | 1.07 Billion |
| High Light: | full color outdoor led display,outdoor full color led screen |
||
Outdoor Led Display P10
L-PH10 Outdoor LED Display Features:
Application areas:intelligent transportation, radio and television industry, stadiums, timing and scoring, theme parks, advertising, information dissemination, themed theater, city exhibition.
High performance waterproof and dust proof
The rating up to IP65,can adapt to all kinds of bad rain weather;tructural parts are made of a special surface treatment process, with good moisture corrosion resistance; electronic circuits are used in three anti-treatment process, to further protect the product against dust, moisture, corrosion, to ensure that products have strong weatherability, can be long-term used in harsh outdoor environments.
Easy to install, reliable
Provide hanging and stacking two installation options. convenient to rapid installation and dissembling. Multiple measures to ensure the reliability, security of the cabinet installation.
Easy maintenance
The product design following the concept of simple maintenance, using modular, redundant design, convenient for product maintenance.
| Specification | L-PH10 | |
| Basic Parameter | Pixel pitch (mm) | 10 |
| Pixel Configuration | 1R1G1BDIP346 | |
| Pixel Density(dot/) | 10000/ | |
| Module Resolution(W×H) | 16*16 | |
| Module Size(mm) | 160*160*30mm | |
| Cabinet Resolution(W×H) | 96*96 | |
| Cabinet Size(mm) | 960*960*80mm | |
| Lighting Parameter | Unit brightness, chroma adjust | yes |
| Brightness | ≥6500CD/ | |
| Gray scale | RGB12-16BitsEach | |
| Color temperature (K) | 6500~9500Adjustable | |
| Horizontal / Vertical Viewing Angle (°) | 110/55 | |
| Control system parameter | Scanning mode | Dynamic |
| Frame Frequency (Hz) | ≥60 | |
| Refresh Frequency (Hz) | 200-2000 | |
| Operating Characteristic | Max Power Consumption (W/m2) | ≤600W/ |
| Average Power Consumption (W/m2) | ≤300W/ | |
| IP Rating | Front IP 65,Back IP 55 | |
| Life Span (hrs) | ≥100,000 | |
| Power supply requirement | AC:220×(1±10%)V,50×(1±5%)Hz | |
| Temperature Range (℃) | -20~50 | |
| Humidity Range (RH) | 10%~90%, Nocondensation |
Packaging:
1:Flight Case(5 cabinets in one case)
Gross Weight:150KG
Size:1010mm*560mm*1175mm
2:Wooden case(5 cabinets in one case)
Gross Weight:180KG
Size:1120mm*585mm*930mm
Buying Guides
In order to offer you a suitable solution,pleasefollow the guides belowing:
1, star effect or video effect which you need.
2,Dimension (Width and Height)
3,Location of installation. (picture is best)
4,Purpose. ( what are you going to do with the LED Curtain)
After-Sale Service
1. One year warranty , Lifetime free maintenance.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on
6. Special service for big project, such as stadium, exhibitions, squares and so on.
Company Information
Shenzhen SCXK Electronics Co.,Ltd has the standard new factory,and about 100 employees.
We have outstanding R&D department and after-sell service workers,and separately design ability.
Our product mainly included led single dual color display,led indoor full color display;led outdoor full color display,led wireless car used screen etc.It can be used on the shopping more,bank,bus station,train station,Center of downtown,airport,school,factory,bus,taxi and son on.
We adapt many methods and very good after-sell service to sell our product all over the world.
Whenever and wherever we are,we always take the principle that is:professional makes good quality,good price product market to provide perfect product and service for our customers.
Certifications:
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3. 36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
