Outdoor Big led screen P8 High Definition Led Display Nationstar Power supply IP65

Outdoor Big led screen P8 High Definition Led Display Nationstar Power supply IP65

  • Outdoor Big led screen P8 High Definition Led Display  Nationstar Power supply IP65
  • Outdoor Big led screen P8 High Definition Led Display  Nationstar Power supply IP65
Outdoor Big led screen P8 High Definition Led Display  Nationstar Power supply IP65
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P8
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: negotiation
Packaging Details: flight case, wooden case
Delivery Time: 7-10 working days
Payment Terms: T/T, T/T
Contact Now
Detailed Product Description
Pixel Density: 15625 Brightness: 7000
Control System: Nova LED Shape & Size: 3mm Smd3535
Module Size: 256*128 Driver Mode: 1/4 Scan
Operation Power: 220V 60HZ Cabinet Size: 1024*1024
Protection Level: IP65
High Light:

rgb led screen

,

full color outdoor led display



P8 High Definition Led Display Outdoor , Epistar Chip Led Advertising Display Screen SMD3535





  • Features of p8 outdoor led display:

1. Wide viewing angle: The specially designed masks can make the horizontal viewing angle up to 150 degrees.

2. Ghost canceling: Exquisite and clear pict quality with no ghost.Both upstream and downstream ghosts can be automatically canceled.

3. Hight refresh rate: Over 1880Hz refresh rate to ensure the picture wrinkle-less,line-less and stable.

4. Low brightness and Hight gray scale: 14Bit-16Bit gray scale to bring excellent performance when brightness is reduced to 20%.



  • Application scopes of p8 outdoor led display: widely applied to outdoor advertisement,stage shows,advertising screes,concerts and so on.



Pixel pitch P8
Module Parameters Pixel pitch 8 mm
Pixel Density 15625 pixels/m2
LED Shape DIP/SMD
LED Configuration 1R1G1B
Module Resolution 40*40/32*16 pixel
Module Size 320*320/256*128
Drive Method 1/4,1/8
Cabinet Parameters Cabinet Resoltuion 80*80/96*96
Cabinet Size 640*640/768*768 mm
Cabinet Weight 63kg/m2
Display Parameters Optical Brightness ≥7000 cd/m2
Viewing angle H/V 120/120
Best Viewing Distance 8-28 m
Display Color 16.7 million
Grey Scale 10bits/1024levels
Power Max power consumption 1000 W/m2
Ave power consumption 500 W/m2
Working Voltage 220V / 110V
Control system Frame Frequency 60--85 HZ
Refresh Rate ≥1200 HZ
Data Transmission CAT 5/ Optic Fiber
Image Source S-Video, PAL/ NTSC
Controlling system linsn, Nova, Mooncell, ZD, Xixun,
Lumen, Dbstar
Format Video Compatibility DVI, VGA, composite
Reliability Working Temperature -20~65 ℃
Working Humidity 10-90% RH
Life Span 100,000 Hours
MTBF (Ave No Faliure Time) 5000 Hours
Pixel failing Rate 0.01%
IP Rate IP 65



Outdoor Big led screen P8 High Definition Led Display  Nationstar Power supply IP65 0



2017 amazing Led display outdoor new advertising led display outdoor HD 3G wireless led street billboard p8



New products instead of tradition street light box, Sunrise is a brand created to make a consistent impression that etches our desired brand image into the minds of our target prospects,

HD advertising video dazzle coming to your life and your business, flourshing everywhere.



Flexible: Shorter lead time, multiple branding exposure and cost effective.

Reachable: Reaching out the unreachable population

Bright: Clear LED Displays on lamp posts along the busiest roads



Company Information
Shenzhen SCXK Electronics Co.,Ltd has the standard new factory,and about 100 employees.
We have outstanding R&D department and after-sell service workers,and separately design ability.
Our product mainly included led single dual color display,led indoor full color display;led outdoor full color display,led wireless car used screen etc.It can be used on the shopping more,bank,bus station,train station,Center of downtown,airport,school,factory,bus,taxi and son on.
We adapt many methods and very good after-sell service to sell our product all over the world.
Whenever and wherever we are,we always take the principle that is:professional makes good quality,good price product market to provide perfect product and service for our customers.

Certifications:

FAQ

1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .

2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.

3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3. 36pcs in one case packaging
4.Customized packaging

4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .

5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
