Transparent LED Screen
Created with Pixso.

IP30 hd Indoor P5.21 Transparent LED Screen Pixel Density 36864 Dots / sqm transparent video screen

IP30 hd Indoor P5.21 Transparent LED Screen Pixel Density 36864 Dots / sqm transparent video screen

Brand Name: SCXK
Model Number: P5.21
MOQ: 1 SQM
Price: negotiation
Payment Terms: T/T
Supply Ability: 3000 sqm per month
Detail Information
Place of Origin:
China
Certification:
CE/ROHS/FCC/ISO/UL
Pixel Density:
36864 Dots/sqm
Brightness:
>4000CD/sqm
Control System:
LSN
Cabinet Size:
500×1000×80mm
Driver Mode:
1/6
Operation Power:
220V 60HZ
Display Color:
1.07 Billion
Refresh Rate:
>1800Hz
Packaging Details:
flight case, wooden case
Highlight:

transparent led display

,

led transparent screen

Product Description

5.21 Transparent LED Screen



Application



The PH5.21-5.21 Transparent LED Screen is highly usable at indoor places like malls, stages, chain stores, hotels, public buildings, bars, restaurants, banks etc. Its thin size and ultra-lightweight module makes it easy to install at any area without covering much space.



IP30 hd Indoor P5.21 Transparent LED Screen Pixel Density 36864 Dots / sqm transparent video screen 0



High Transparent Effect



It features transparent effect up to 70% keeping the perspective function of glass. The higher transparency effect allows you to see LED light on the glass without any effect to surround of glass wall.



High Brightness, Better Quality

The high brightness and high definition features of the PH5.21-5.21 Transparent LED Screen ensures great quality pictures - making it a perfect fit for stage, banks, glass wall, promotion, station, stadium and other

indoor places.



Specification

LED Module
Pixel Density 36838 Dots/sqm
module layout Horizontal/Vertical
Module Size 250×250mm
module Resolution 48×48dot
LED Cabinet
Cabinet Size 500×1000×65mm
Transparency 70%
Cabinet Resolution 96×192dot
Cabinet Weight 7kg/Panel
IP Rating( front/back) IP30
Brightness >4000CD/sqm
Viewing Angle(H/V) 140o/140o
Viewing Distance >6m
Grey Scale Levels 16bit
Max.Power Consumption 850 W/sqm
Ave.Power Consumption 340 W/sqm
Refresh Rate  >1800Hz
Environment Indoor
Drive Mode/Driver Position Constant driving 1/6 Scan
Display Function Text,Graphics,Video
Input Voltage AC110-220V±10%,50/60Hz
Operating Temperature - 20oC~50oC
Operating Humidity 10%~90%
MTBF( mean time between failures) 5000 hours
Operating Life 100,000 hours
Control System
Control Method Synchronization/Asynchronization
Control System Sending Card, Receiving Card,Receiving HUB
Input Signal AVI/MPG/MPEG/TXT.etc
PC Operating System
Communication Type Net cable; 3G, WIFI(Sold separately)
Software Nova Studio( HSTV-Nova)
Language Chinese, Traditional Chinese, English, French, Spanish, Korean, Japanese, German, Russian
Certificate CE,ROHS,FCC,ISO9001, TUV
Control Card Inputs DVI,HDMI



Silence Operation - Low Power Consumption

The Transparent LED Screen for Shopping Mall is known for its silence operation and low power consumption. It is also known for fast heat dissipation which will save more energy. Cut on the electricity expenses and help environment with this highly advanced advertising display.



Unique Cabinet Design - Easy to Install & Transport

Single light bar can be directly plugged in and pulled out which is easy to install and save time and effort. The portable cabinet is easy to carry and can also save transportation cost for you.



Integrated Design, Fast Installation

The thin size and ultra-lightweight modules makes it easy to carry, transport and install. You hardly need any specialized tools or skills to install it. Everything is inbuilt, and it can be installed within a few minutes using simple screw-driver.



  • FAQ

1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3. 36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
