P6 Outdoor LED Billboard SMD 2121 Full Color IP65 Waterproof

P6 Outdoor LED Billboard SMD 2121 Full Color IP65 Waterproof

Product Details:
Place of Origin: Shenzhen China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: 3 sqm
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 5000 sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 6mm Tube Chip Color: Full Color
Led Type: SMD 2121 Display Function: Video/Text/Image
Viewing Angel: H:160°,V:140° Relative Humidity: ≤95%RH
Regular Cabinet Size: 960mmx960mm Waterproof: IP65
Warranty Time: 3 Years IC: MBI 5024 IC
Highlight:

outdoor advertising led display

,

advertising led billboard

Energy Saving Big Advertising Billboard P5 P6 P10 Sign Outdoor Led Display Screen
Product Specifications
Attribute Value
Pixel Pitch 6mm
Tube Chip Color Full color
Led Type SMD 2121
Display Function Video/Text/Image
Viewing Angel H:160°,V:140°
Relative humidity ≤95%RH
Regular cabinet size 960mmx960mm
Waterproof IP65
Warranty time 3 years
IC MBI 5024 IC
High Brightness SMD P6 Outdoor Advertising Led Billboard With 3 Years Warranties

The high resolution LED billboard delivers exceptional quality pictures and videos to broad audiences. Ideal for outdoor advertising applications including banks, stages, promotions, exhibitions, highways, stations, stadiums and other outdoor venues.

IP65 Protection Rating and Modular Design

The specialized waterproof design of our P6 SMD Outdoor LED Billboard provides superior protection against water and dust ingress. The IP65 rating ensures reliable performance in all environmental conditions.

P6 Outdoor LED Billboard SMD 2121 Full Color IP65 Waterproof 0
Energy Efficient Power Supply

Our outdoor fixed displays utilize premium power supplies with electro-optic conversion ratios up to 82%, resulting in low heat dissipation and extended lifespan. Standard power supplies typically offer less than 80% conversion efficiency with higher heat output.

P6 Outdoor LED Billboard SMD 2121 Full Color IP65 Waterproof 1
Technical Parameters
Parameter Specification
Lamp size 3535
Resolution/mm 6
Pixel configuration RGB 3 in 1
Pixel density/pixels/m² 62500/m²
Module resolution 32x32
Module size/mm 192*192
View distance ≥5m
White balance brightness >4500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120°
Vertical view angle 120°
Frame rate 60Hz
Refresh frequency >1200Hz
Working hours ≥72hours
Life time 100000hours
Operating temperature range -20°C to 45°C
Average power consumption <300W/㎡
P6 Outdoor LED Billboard SMD 2121 Full Color IP65 Waterproof 2
Key Features
  • Super lightweight and thin profile
  • Simple connection and installation
  • Displays words, texts, graphics, pictures and videos
  • High resolution with excellent dynamic image quality
Our Manufacturing Advantages
  • OEM services available with no minimum order quantity
  • Easy installation with regular items in stock
  • Custom design drawings available upon request
  • Remote control and adjustment capabilities
  • Flexible packaging options including wooden or flight cases
  • 24-hour response time for all inquiries
  • Fast delivery within 6-8 working days
  • Expert R&D team ensuring factory-direct quality
Packaging and Shipping

Available in wooden cases or flight case packaging. Multiple shipping options including sea, air or express courier services.

Why Choose Our Products

Continuous Quality: With over 10 years of LED display manufacturing experience, we maintain regular equipment updates and standardized module production to ensure consistent product quality.

Competitive Pricing: Our large-scale production capacity and efficient manufacturing processes enable us to offer competitive pricing without compromising quality.

Reliable Delivery: We honor all delivery commitments, implementing special procedures when necessary to maintain uninterrupted supply.

Comprehensive Service: From pre-sales consultation to after-sales support, we provide complete service throughout the product lifecycle.

Display Cabinet
P6 Outdoor LED Billboard SMD 2121 Full Color IP65 Waterproof 3

Our professional team is committed to providing full support for all your LED display needs.
