Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.

|
| Place of Origin: | ShenZhen in China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/CB/UL |
| Model Number: | P6 |
| Minimum Order Quantity: | 1 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | Western Union, MoneyGram, D/P, T/T, L/C |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | 6mm | Display Function: | Video/Text/Image |
|---|---|---|---|
| Voltage: | DC5V | Refresh Rate: | >=1920HZ |
| Maximum Power: | 800 W/㎡ | Module Size: | 192mmx192mm |
| Brightness: | ≥5000 Cd/m2 | Pixel Density: | 10000 |
| Driving Mode: | 1/8 Scan | IC: | MBI 5024 IC |
| Highlight: | led video screen rental,led rental screen |
||
High Quality Outdoor Fixed Installation LED Billboard P6 Digital LED Panels Advertising LED Sign
♦ Description:
•With sensitive control system, it can adjust screen brightness automatically according to the lighting change of indoor and outdoor, saving energy to reduce your operating costs greatly.
•High refresh rate and high gray make the picture more realistic, which meets the demand of high visual quality of commercial usage.
•The advertising contents can be changed at any time, for different customers and various advertisements.
•you can know the display operation anytime, anywhere.
• It can turn on and turn off the screen by software timing or manually at any time, achieving unattended function.
Fixed P6 outdoor full color led display smd 3535 with 3 years warranty
1. p6 outdoor digital led billboard
2. Factory price and good quality
3. Environmental-friendly and energy-saving.
4. Convenient and easy maintenance
5. Good heat dissipation capability because of the unique design of vent fan.
Our advantage
1. High quality:100% tested before shipping, Best quality LED chip tube the CREE, SILAN, OPTO, EPISTAR assuring high brightness and long life span. industry-leading
2. Strong productivity: 8000 square meters per month, Shorter delivery time
3. Good price:our price is 10% lower than the market because of the introduction of full
automatic production line with the characteristics of reducing the cost of labor and management.
4. Stable performance:our most basic guarantee:the aging time exceeding 24 hours. Malfunction
dot rate less than 0.0001. MTBF more than 1000 hours.
5. Any questions can be answerd quickly within 24 hrs.
The Outdoor P6 SMD Led Display Paramter as Follow
| Outdoor DIP / SMD P6 | |
| Resolution/mm | 6 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 27778m2 |
| Module resolution | 32*32 |
| Module size/mm | 192*192 |
| View distance | 7-500m |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Driving mode | Constant driving current |
| Scanning mode | 8dring |
| Frame rate | 60Hz |
| Refresh frequency | 3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Maximun power :/m2 | <800w |
| Average power:/m2 | <300w |
| Self-check technolog | LEDspot self-check,communication check,power check,temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control,record potential fault send out warning signs to the operators(need customization) |
| Software environment | windows NT,Windows 1999,Windows XP |
♦ Applications
--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.
Installtion
♦ Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
Contact Person: Susan_zhang
Tel: +8618344159301
