P10 Outdoor LED Display for Stadiums IP65 Waterproof 10mm Pixel

Product Details:

Place of Origin:	ShenZhen in China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/UL
Model Number:	P10

Payment & Shipping Terms:

Minimum Order Quantity:	5 sqm
Price:	negotiation
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-10 working days after receive your payment
Payment Terms:	T/T,Western Union,MoneyGram,L/C
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixels:	10mm	Tube Chip Color:	Full Color
Waterproof:	Ip65	Cabinet:	Steel Or Aluminum For Options
Frame Frequency:	>=60HZ	Average NO Failure:	>=1000hours
Viewing Angle:	H:160 V:140
Highlight:	perimeter led display , perimeter led screen

P10 Outdoor LED Advertising Boards Football Stadium Led Display Score Board Screen

Product Specifications

Attribute	Value
Pixels	10mm
Tube Chip Color	Full color
Waterproof	IP65
Cabinet	Steel or Aluminum For Options
Frame Frequency	>=60HZ
Average NO Failure	>=1000hours
Viewing angle	H:160 V:140

Product Description

High Brightness P10 Outdoor Full Color LED Display For Stadium Sport Live Show

Quick Details:

P10 mm pixel RGB, HD, big density, very bright
3 years' warranty for entire screen
On-site professional service
Hotline service, fast response
Adequate spare parts supply
Regular maintenance service
Technical support on upgrades and replacement

Control System

Product Specifications of Stadium LED Display

Outdoor rental screen mainly used for outdoor events, stage background, or other kinds of live shows. Portable and practical design always brings customers convenient and comfortable experience.

LED Module Parameters

Pixels pitch:	10mm	Pixel density:	10000dot/m2
Pixel configuration:	1R1G1B	Module pixels:	32x16=512 dots
Module size:	320x160x25mm	Module weight:	0.65KG
Configuration feature:	Integrated Light/Driver	Frame material:	Polycarbonate(PC)
Input voltage:	AC 4.8-5.5V	Max current:	6.0A±0.1A
Module power consumption:	30W	Driver mode:	1/4 scan

LED Cabinet Parameters

Standard cabinet size:	960x960x95 mm
Cabinet pixel:	96x96=9216dots
Cabinet square:	0.9216m2
Cabinet weight:	45KG
Max power consumption:	750W
Average power consumption:	350W

LED Display Parameters

Brightness:	≥5000cd/m2	Brightness homogeneity:	≥0.95
Best horizontal view angle:	100±8°	Best vertical view angle:	70±5°
Best view distance:	≥10m	Blind spot rate:	≤0.0003
Max power consumption:	1000W/m2	Application condition:	Outdoor

System Control Parameters

Gray scale:	each R, G, B - 65536	Color:	16777216 kinds
Repetition rate:	≥60 frame/second	Refresh rate:	≥1400Hz
Control method:	PC control, video synchronization	Brightness adjusting:	256 auto/manual
Input signal:	DVI/VGA, RGBHV, S-VIDEO, HDTV and so on

System Working Features

Lifespan:	≥100,000 hours	MTBF:	≥10,000 hours
Attenuation rate:	≤15% 3 years working	Out of control dots:	0
Discrete control dot:	0 (before shipment)	Blind spot rate:	0 (before shipment)
Working temperature:	-20 ~50 °C	Working humidity:	10%~90%RH
Protection feature:	Over-heat, over-load, image complement, overcurrent, overvoltage, anti-thunder (optional)

Features of LED Stadium Display

Fast assemble & Disassemble
High brightness & Waterproof
No Ghosting, no flicker
Ultra slim & Light weight
Seamless & Flatness

Our Services

Reply your inquiry in 24 working hours
Free training: You can send engineers to our factory for training who have knowledge of electronics
Customized design is available, OEM & ODM are welcomed
Exclusive and unique solution can be provided by our professional engineers
Special discount and protection of sales area provided to our distributor
Warmly welcome your visit in our company if available
Warranty: 24 months, a little investment for longer warranty time

FAQ

Why Choose Us?

More than 8 Years experience on Producing LED module. We focus on Quality and Service, and keep your price competitive in your local markets.

How to Check quality?

Our products all use good quality LED materials, like PCB, plastics, LED lamps, ICs, etc. You or your friend can come to our factory before production or after production. Before you place order, in production and after production, we will take some pictures on related products. We promise everything is same as we discussed on products.

How do you improve quality?

Find problems and solve problems. As a professional manufacturer in LED field, we pay close attention to material quality in different times, and send information back to supplier. Every customer can give us feedback on any products, then we can check.

How could I know to control LED display?

Firstly, if we sell screen for you, control system was be set up in advance by us; or if you buy different spare parts (like module, control card, power supply) from us, we also can set up control system in advance, and we can recommend right control card for you. Second, we can help you set up LED screen by teamviewer or send RCG file to you if you can't finish set up by yourself in your there.

If any products have problems, how to do?

Firstly, we hope you can receive perfect products when goods arrive your hands. All orders will give some free spare parts, like LED lamps or ICs, you can do some simple repairing works. If you purchase LED screen, please don't forget to buy small quantity module for spare.

Every Customer should know:

LED module may have some color difference, if you order one type product two more times.

Video Pixel Pitch 10mm Outdoor P10 LED Advertising Stadium Display
