Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65

Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65

  • Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65
  • Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65
  • Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65
  • Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65
Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCX
Certification: CE,ISO,FCC,UL
Model Number: SCX-P10
Payment & Shipping Terms:
Minimum Order Quantity: 3sqm
Price: 412-578USD/sqm
Packaging Details: Carton,wooden and flight cases.
Delivery Time: 12-15 working days.
Payment Terms: T/T, Western Union
Supply Ability: 5000sqm/month
Contact Now
Detailed Product Description
Usage: Outdoor Tube Chip Color: Full Color
Display Function: Video Pixels: 10mm
Screen Dimension: Customized Size Led Chip: Epistar
Module Size: 320x160mm Weight: 45KG/PCS
Power Supply: Meanwell Life Span: 100000hours
Highlight:

advertising led billboard

,

outdoor advertising led display

P10 Outdoor Large Display Advertising LED Screens Iron Cabinet IP65 HD Digital



SMD P10
Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000dots/square meter
Module resolution 32x16mm
Module size/mm 320x160mm
View distance 10-60m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 5000cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4 SCANNING
Frame rate 60Hz
Refresh frequency 1200Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Normal questions:



Q1: What's the pixel pitch for choice?
A1: Indoor series: P1.25, P1.56, P1.667, p1.875,p2,p2.5,p2.6,p3,p3.91,p4
      Outdoor series: P4.8, P5.9 MG5 outdoor series: P5.9, P6.9, P7.8, P8.9, P10.4

Q2: Where is it used for?
A2: Performance shows, sports activities, advertising, information publishing, celebrating activities, hotel entertainment ect.
One type realize Multi Function for creative stage led screen, advertising led screen, sky backdrop curtain, stadium screen, dance floor and Outdoor screen for indoor use.

Q3: Can it play HD video?
A3: Yes, it can realize HD video function with several different controlling systems,such as Nova, Mooncell,linsn and so on.


Q4: What after service can provide?
A5: One year warranty, 24h online technical support, back-visiting customer for each year

Sending technical personnel to the scene in customers significant activities



Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65 0Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65 1Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65 2Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65 3Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65 4Rental Screen P10 Outdoor Waterproof Large Display Advertising LED Screen Iron Cabinet IP65 5

Advantage

1. High brightness: Due to the use of high-brightness LED lights, viewers can see the image clearly at a long distance under strong sunlight.

2. Long service life: Using high-quality LED lights as the core material, the screen adopts patented PCB design, which fundamentally guarantees the long life of the product.
Fundamentally guarantees the long life of the product.

3. Stable performance: Special treatment is carried out to combat electromagnetic waves, and the screen adopts distributed scanning and modular design, with stable performance.
Modular design, more reliable and stable work.

4. Delicate image: Non-linear correction technology makes the image delicate and clear, and the video image vivid and lifelike.

5. Excellent flatness: The precision design of the module frame components controls the deviation of adjacent modules within 0.1 mm, with excellent flatness and no mosaic phenomenon.
